18450-24F03 !  VALVE ASSY, 2ND AIR | MODEL X/Y/K1
18450-24F03  VALVE ASSY, 2ND AIR | MODEL K2/K3
07130-0635B !  BOLT, MAGNETO STATOR
18630-24F10  SPACER, 2ND AIR VALVE SUPPORT
09320-10015  CUSHION, 2ND AIR VALVE SUPPORT
09160-06088  WASHER, 2ND AIR VALVE SUPPORT
08316-1006B !  NUT
18610-24F01  BRACKET, 2ND AIR VALVE
09103-06285 !  BOLT
18620-24F00  BRACKET, 2ND AIR VALVE BRACKET
09355-35755-00B  HOSE, VACUUM (3.5X7.5X2000) | L:2000!650
18711-24F00  HOSE, 2ND AIR CLEANER
09401-15101  CLIP
18461-24F00  HOSE, 2ND AIR VALVE FR
18491-24F00  HOSE, 2ND AIR VALVE RH
09401-13409  CLIP
18410-24F00  PIPE, 2ND AIR NO.1
18420-24F00  PIPE, 2ND AIR NO.2
18430-24F00  PIPE, 2ND AIR NO.3
18440-24F00  PIPE, 2ND AIR NO.4
18441-45C01  GASKET, 2ND AIR PIPE
01421-0616A !  BOLT,STUD
08316-1006B !  NUT
09404-06432  CLAMP, 2ND AIR VACUUM HOSE
13700-24F04 !  CLEANER ASSY,AI | MODEL X
13700-24F04 !  CLEANER ASSY,AI | MODEL Y
13700-24F04 !  CLEANER ASSY,AI | MODEL K1/K2/K3; Includes Item(s) 2 - 13
13780-24F02 !  FILTER ASSY | MODEL X/Y
13780-24F02 !  FILTER ASSY | MODEL K1
13780-24F02  FILTER ASSY | MODEL K2/K3
13831-21F00  SCREW
13736-01H00 !  CUSHION, DUCT | MODEL X/Y/K1
13736-01H00 !  CUSHION, DUCT | MODEL K2/K3
13881-33E50  TUBE, OUTLET
13881-24F00  TUBE, OUTLET
13826-33E52 !  CLAMP
13850-24F00  TUBE, BREATHER | MODEL X
13850-24F10 !  TUBE, BREATHER | MODEL Y
13850-24F10 !  TUBE, BREATHER | MODEL K1
13850-24F10  TUBE, BREATHER | MODEL K2/K3
09401-14301  CLIP
13895-24F00  DIAPHRAGM, CONT VALVE
13872-00110  CAP, DRAIN | MODEL X/Y
13859-41B10  PLUG, BREATHER
09401-14301  CLIP
09116-06130  BOLT (6X16)
18115-70G10  VALVE ASSY, SOLENOID
95569-78040  VALVE, CHECK
09407-14403  CLAMP, CHECK VALVE
18119-33E00  BRACKET, SOLENOID VALVE
09180-06257  SPACER
09320-09036  CUSHION
09116-06115  BOLT
13715-02F00  CHAMBER, VACUUM
02142-0512A !  SCREW
09367-04009  3 WAY
09355-40805-600  HOSE, VACUUM CHAMBER TO 3 WAY (4X8X600) | L:600!40
09355-40805-600  HOSE, 3 WAY TO SOLENOID (4X8X600) | L:600!150
09355-40805-600  HOSE, CHECK VALVE TO 3 WAY (4X8X600) | L:600!100
09355-40805-600  HOSE, SOLENOID TO CLEANER (4X8X600) | L:600!400
15620-02F00  SENSOR, BOOST
02142-0610A !  SCREW
13650-61B00  SENSOR, AIR TEMPERATURE
09168-12016  GASKET | MODEL X/Y/K1
09168-12017  GASKET | MODEL K2/K3
18590-81A00  SENSOR, AIR PRESSURE
02142-0612A !  SCREW, COVER
33610-02F01 !  BATTERY ASSY | MODEL X/Y/K1 YT12A-BS,12V,10AH
33610-02F01  BATTERY ASSY | MODEL K2/K3 YT12A-BS,12V,10AH
33651-37000  PROTECTOR (170X95X3.0) | CUT AS REQUIRED PROFILE (20X90)(115X50)
33652-19F00  PROTECTOR (40X85X5) | MODEL X/Y/K1
33651-37000 !  PROTECTOR | MODEL K2/K3
33810-24F00  WIRE, STARTER MOTOR LEAD | Includes Item(s) 4
31861-48B10  CAP, STARTER MOTOR
33820-24F00  WIRE, BATTERY PLUS LEAD | Includes Item(s) 6
33624-35B00  CAP, BATTERY PLUS
33860-24F00  WIRE, BATTERY MINUS
51410-24F30 !  BRACKET, LOWER | MODEL X/Y/K1/K2
51410-24F30  BRACKET, LOWER | MODEL K3; Includes Item(s) 2 - 3
51644-12C00  SEAL, LOWER
09267-30010  BEARING (30X55X17)
01550-08407  BOLT
51311-24F00  BRACKET, UPPER
09164-08015  WASHER
07130-08357  BOLT
51356-27C00  WASHER
51353-24F00  NUT
09267-30010  BEARING (30X55X17)
51644-12C00  SEAL, DUST UPPER (30.1X56X4)
51643-24F10 !  SEAL, STEERING (30.1X75X6) | MODEL X/Y/K1
51643-24F10  SEAL, STEERING (30.1X75X6) | MODEL K2/K3
51641-33E00  WASHER, STEM
51631-33E00  NUT, STEM
51750-24F00  DAMPER ASSY, STEERING | Includes Item(s) 16
09269-08003  BEARING (8X17.5X11)
64339-14101  SEAL, DUST
07130-08307  BOLT
08319-31107  NUT
12760-24F01 !  CHAIN,CAM SHAFT DRIVE (128LE)
12771-24F00  GUIDE, CAM CHAIN NO.1
12782-24F01  GUIDE, CAM CHAIN NO.2
07130-0612A !  BOLT
12811-24F11 !  TENSIONER, CAM CHAIN
12812-26B02  BOLT
12773-24F00  RETAINER, CAM CHAIN GUIDE NO.1
02122-0612A !  SCREW
12800-24F11 !  ADJUSTER SET, TENSIONER | Includes Item(s) 10 - 13
12836-24F00  SHAFT, ADJUSTER
12837-24F10  GASKET
12833-05A00  PLUG
12831-24F10  SPRING
12837-24A10  GASKET, TNSN ADJUSTER
07130-0625B !  BOLT
12835-24F00  HOSE, CAM CHAIN TENSIONER
12838-35F01 !  BOLT
09168-08016 !  GASKET, LH
12839-24F00  PLUG
09168-14004 !  GASKET
12710-24F00  CAM SHAFT, INTAKE
12720-24F00  CAM SHAFT, EXHAUST
09390-47002  C RING
12891-02F00  TAPPET
12911-24F00  VALVE, INTAKE
12912-24F00  VALVE, EXHAUST
12920-24F00  SPRING SET, VALVE
12931-02F10  RETAINER, VALVE SPRING
12933-38400  SEAT, VALVE SPRING
12932-24F00  COTTER, VALVE
09289-05011  OIL SEAL (4.5X10X8)
12892-41C00-230  SHIM, TAPPET (T:2.30)
12892-41C00-235  SHIM, TAPPET (T:2.35)
12892-41C00-240  SHIM, TAPPET (T:2.40)
12892-41C00-245  SHIM, TAPPET (T:2.45)
12892-41C00-250  SHIM, TAPPET (T:2.50)
12892-41C00-255  SHIM, TAPPET (T:2.55)
12892-41C00-260  SHIM, TAPPET (T:2.60)
12892-41C00-265  SHIM, TAPPET (T:2.65)
12892-41C00-270  SHIM, TAPPET (T:2.70)
12892-41C00-275  SHIM, TAPPET (T:2.75)
12892-41C00-280  SHIM, TAPPET (T:2.80)
12892-41C00-285  SHIM, TAPPET (T:2.85)
12892-41C00-290  SHIM, TAPPET (T:2.90)
12892-41C00-295  SHIM, TAPPET (T:2.95)
12892-41C00-300  SHIM, TAPPET (T:3.00)
12892-41C00-305  SHIM, TAPPET (T:3.05)
12892-41C00-310  SHIM, TAPPET (T:3.10)
12892-41C00-315  SHIM, TAPPET (T:3.15)
12892-41C00-320  SHIM, TAPPET (T:3.20)
12892-41C00-325  SHIM, TAPPET (T:3.25)
12892-41C00-330  SHIM, TAPPET (T:3.30)
12892-41C00-335  SHIM, TAPPET (T:3.35)
12892-41C00-340  SHIM, TAPPET (T:3.40)
12892-41C00-345  SHIM, TAPPET (T:3.45)
12892-41C00-350  SHIM, TAPPET (T:3.50)
12800-41810  SHIM SET, TAPPET INC. REF.NO.12-5%12-25 (5PCS. EACH) & NO.14 | OPT NOT SHOWN; Includes Item(s) 14
99000-69471  CASE, TAPPET SHIM | OPT NOT SHOWN
21200-24810 !  GEAR ASSY, PRIMARY DRIVEN
09160-25037  WASHER (25X54X2.5)
09263-35013  BEARING (35X40X39.8)
21410-24F00  HUB, CLUTCH SLEEVE
21610-02F12  CAM SET, CLUTCH
21481-02F12 !  BOLT, SPRING SUPPORT
21413-24F10  SPRING, CLUTCH
21482-02F12 !  BOLT, CLUTCH SPRING
21441-24F00 !  PLATE, CLUTCH DRIVE NO.1 | T:3.0
21441-24F10  PLATE, CLUTCH DRIVE, NO.2 | T:3.8
21451-24F00  PLATE, CLUTCH DRIVEN NO.1 | T:2.0
21451-24F10  PLATE, CLUTCH DRIVEN NO.2 | T:2.3
21442-24F00  PLATE, CLUTCH DRIVE NO.3 | T:3.8
21471-24F00  SEAT, WAVE WASHER
21472-24F00  WASHER, CLUTCH PLATE WAVE
21462-24F00  DISK, CLUTCH PRESSURE
09159-24010  NUT, CLUTCH SLEEVE HUB
09160-25056  WASHER (25X50X25)
09164-24006  WASHER (24.2X35X2)
23110-24F00  ROD, CLUTCH PUSH, RH
23111-26D00  ROD, CLUTCH PUSH, LH
23121-31E00  PIECE, CLUTCH PUSH
23160-06B03 !  CYLINDER,CLUTCH | Includes Item(s) 24 - 27
23163-06B00  CUP
23164-05A00  SPRING
59121-01A00  BLEEDER
59122-01A00  CAP, BLEEDER
04211-09129  PIN, CL RLSE CYL
07130-0625B !  BOLT
09160-15045  WASHER, CLUTCH PUSH | 15.5X28X1
09263-15003  BEARING (15X28X2)
09285-06015  SEAL (6X34X5.5)
21200-24810 !  GEAR ASSY, PRIMARY DRIVEN
09160-25071  WASHER (25.1X54X2.5) | MODEL X/Y
09160-25037  WASHER (25.1X54X2.5) | MODEL K1
09263-35013  BEARING (35X40X39.8)
21410-24F00  HUB, CLUTCH SLEEVE
21610-02F12  CAM SET, CLUTCH
21481-02F12 !  BOLT, SPRING SUPPORT | MODEL X
21481-02F12 !  BOLT, SPRING SUPPORT | MODEL Y/K1
21413-24F10 !  SPRING, CLUTCH | MODEL X
21413-24F10  SPRING, CLUTCH | MODEL Y/K1
21482-02F12 !  BOLT, CLUTCH SPRING | MODEL X
21482-02F12 !  BOLT, CLUTCH SPRING | MODEL Y/K1
21441-24F00  PLATE, CLUTCH DRIVE NO.1
21441-24F10  PLATE, CLUTCH DRIVE NO.2
21451-24F00  PLATE, CLUTCH DRIVEN NO.1
21451-24F10  PLATE, CLUTCH DRIVEN NO.2
21462-24F00  DISK, CLUTCH PRESSURE
09159-24010  NUT, CLUTCH SLEEVE HUB
09160-25072  WASHER (25X50X2.5)
09164-24006  WASHER, CLUTCH SLEEVE | 24.2X35X2
23110-24F00  ROD, CLUTCH PUSH RH
23111-26D00  ROD, CLUTCH PUSH LH
23121-31E00 !  PIECE, CLUTCH PUSH
23160-08A03 !  CYLINDER,CLUTCH | Includes Item(s) 21 - 24
23163-05A00  CUP
23164-05A00  SPRING
59121-01A00  BLEEDER
59122-01A00  CAP, BLEEDER
04211-09129  PIN, CL RLSE CYL
07130-0625B !  BOLT
09160-15045  WASHER, CLUTCH PUSH | 15.5X28X1
09263-15003  BEARING, CLUTCH PUSH | 15X28X2
09285-06015  SEAL, CLUTCH PUSH | 6X34X5.5
59800-24F01 !  CYLINDER ASSY,C | Includes Item(s) 2 - 12
59800-08810  PISTON/CUP SET
59666-44300  BOOT
59871-32F00 !  PUSH ROD
59892-08A00  BUSH
59664-48B00  PROTECTOR
59667-49460  DIAPHRAGM
59668-41C00  PLATE
59669-41C00  CAP
69689-49300  SCREW
59671-36500  HOLDER
59675-02FA0  BOLT (6X22)
59910-24F10 !  HOSE, CLUTCH | MODEL X
59910-24F10 !  HOSE, CLUTCH | MODEL Y/K1/K2/K3
09360-10062 !  BOLT, UPPER
09360-10061 !  BOLT (10X1.00X22)
09161-10009  WASHER (10X15X1.5)
59915-24F00  CLAMP, HOSE NO.1
01550-0612A !  BOLT, REAR COMB BRACKET
59921-24F00  CLAMP, HOSE NO.2
01550-0616A !  BOLT
94510-24F01 !  BRACE, COWLING | MODEL X/Y
94510-24F01  BRACE, COWLING | MODEL K1/K2/K3
01550-0840A !  BOLT
94541-41C00  CUSHION, BRACE
09180-08215 !  SPACER
08313-2008A !  NUT
94421-24F01 !  PIPE, AIR INTAKE RH | MODEL X/Y/K1
94421-24F01  PIPE, AIR INTAKE RH | MODEL K2/K3
94431-24F02 !  PIPE, AIR INTAKE LH | MODEL X/Y/K1
94431-24F02  PIPE, AIR INTAKE LH | MODEL K2/K3
09136-05054  SCREW, INTAKE PIPE | MODEL X
09139-05054  SCREW, INTAKE PIPE | MODEL Y/K1/K2/K3
09139-05055  SCREW, UPPER PANEL
09409-06314-5PK  CLIP (BLACK)
09139-05054  SCREW
09320-08028  CUSHION
94401-24F10-CN5  COWLING ASSY, BODY
94401-24F10-FH5  COWLING ASSY, BODY
94401-24F10-FH6  COWLING ASSY, BODY | Includes Item(s) 2 - 2
68641-14F30-M5P  EMBLEM | FOR CN5
68641-14F30-F3H  EMBLEM | FOR FH5
68641-14F30-FJ6  EMBLEM | FOR FH6
94611-24F00  WINDSCREEN
09139-05025  SCREW
08322-0105A !  WASHER, FRONT
09159-05019  NUT
94641-24F00  PANEL, UPPER RH
94651-24F00  PANEL, UPPER LH
94419-24F00  COVER, BODY COWL
94401-24F30-YZX  COWLING ASSY, BODY | GSX1300RK2
94401-24F30-FH9  COWLING ASSY, BODY | GSX1300RK2
94401-24F20-HE6  COWLING ASSY, BODY | GSX1300RK2
94401-24F40-019  COWLING ASSY, BODY (BLACK) | GSX1300RZK2; Includes Item(s) 2 - 2A
68281-24F20-HT6  TAPE, FRONT | GSX1300RK2 FOR YZX
68281-24F20-HT7  TAPE, FRONT | GSX1300RK2 FOR FH9
68281-24F10-HT8  TAPE, FRONT | GSX1300RK2 FOR HE6
68641-24F00-JB5  EMBLEM | GSX1300RZK2 FOR 019
94611-24F00  WINDSCREEN
09139-05025  SCREW
08322-0105A !  WASHER, FRONT
09159-05019  NUT
94641-24F00  PANEL, UPPER RH
94651-24F00  PANEL, UPPER LH
94419-24F00  COVER, BODY COWL
94401-24F60-CN5  COWLING ASSY, BODY | GSX1300RK3
94401-24F60-KT7  COWLING ASSY, BODY | GSX1300RK3
94401-24F70-LA1  COWLING ASSY, BODY | GSX1300RK3
94401-24F40-019  COWLING ASSY, BODY (BLACK) | GSX1300RZK3 E28
94401-24F70-YAV  COWLING ASSY, BODY (ORANGE) | GSX1300RZK3 E3,E33; Includes Item(s) 2 - 3
68281-24F10-CN5  EMBLEM | GSX1300RK3 FOR CN5
68281-24F10-KT7  EMBLEM | GSX1300RK3 FOR KT7
68281-24F20-GW5  EMBLEM | GSX1300RK3 FOR LA1
68281-24F20-MZ6  EMBLEM | GSX1300RZK3 E3,E33 FOR YAV
68641-24F00-JB5  EMBLEM | GSX1300RZK3 E28 FOR 019
94611-24F00  WINDSCREEN
09139-05025  SCREW
08322-0105A !  WASHER, FRONT
09159-05019  NUT
94641-24F00  PANEL, UPPER RH
94651-24F00  PANEL, UPPER LH
94419-24F00  COVER, BODY COWL
94401-24F02-M9S !  COWLING ASSY,BO | MODEL X
94401-24F02-M9T !  NO DESCRIPTION AVAILABLE | MODEL X
94401-24F02-CN4 !  COWLING ASSY,BO | MODEL Y
94401-24F02-CN5 !  COWLING ASSY,BO | MODEL Y
94401-24F02-M9T !  NO DESCRIPTION AVAILABLE | MODEL Y E28 FOR M9T; Includes Item(s) 2 - 2
68641-19F00-29F  EMBLEM (BROWN) | FOR M9S
68641-19F00-Y2D  EMBLEM (SILVER) | FOR M9T,CN4,CN5
94611-24F00  WINDSCREEN
09139-05025  SCREW
08322-0105A !  WASHER, FRONT
09159-05019  NUT
94641-24F00  PANEL, UPPER RH
94651-24F00  PANEL, UPPER LH
94419-24F00  COVER, BODY COWL
12650-24F01-0F0 !  SHAFT, CRANK BALANCER
12654-24F00-0F0  BALANCER, CRANK
12666-24F00  GEAR, CRANK BALANCER
12686-24F00  DAMPER, BALANCER GEAR
09263-19015  BEARING
09180-19014  SPACER
09169-21001  WASHER
09280-17004  O RING, LH (D:1.9,ID:16.6)
12681-26D01 !  ARM, BALANCER SHAFT
07130-0620B !  BOLT
09103-06286 !  BOLT, REAR
11301-24880 !  CRANKCASE SET | MODEL X %F.NO.X2103635
11301-24880 !  CRANKCASE SET | MODEL X F.NO.X2103636%
11301-24880 !  CRANKCASE SET | MODEL Y
11301-24880 !  CRANKCASE SET | MODEL K1
11302-24813 !  CRANKCASE SET | MODEL K2
11302-24813 !  CRANKCASE SET | MODEL K3; Includes Item(s) 2 - 42
11319-33E50  PIN
11323-24F00  SEPARATOR, OIL
01547-0625B !  BOLT
11328-24F00  UNION, BREATHER OIL
09168-10031  GASKET, CRANKCASE BOLT (10.2X20X2.3)
01547-0612B !  BOLT
09103-09008  BOLT (9X95)
09103-09010  BOLT (9X115)
09168-08016  GASKET
01547-0650B !  BOLT
01550-0865A !  BOLT
01550-0880A !  BOLT
01550-1060A !  BOLT
01547-0640B !  BOLT
01547-0640B !  BOLT | F.NO.X2103636%
01547-0660B !  BOLT, CRANKCASE
01550-0860A !  BOLT, SEC CASE | %F.NO.X2100438
09103-08155  BOLT (8X50) | F.NO.X2100439%
01550-0850B !  BOLT, SEC CASE | %F.NO.X2100438
09103-08355  BOLT (8X60) | F.NO.X2100439%
11393-33E01  JET, MAGNETO COOLING
09493-20012  JET, T/M COOLING
09168-06023  GASKET, T/M COOLING
07120-0612B !  PLUG
11390-34E00  JET, PISTON COOLING RH
11390-34E10  JET, PISTON COOLING LH
09280-04004  O RING
09106-06075  BOLT
09106-06076  PLUG, PISTON JET OIL GALLERY
09493-36006  JET, T/M OIL 180
11532-46E00  JET, OIL GALLERY
07120-0612B !  PLUG
09168-06023  GASKET
07130-0816A !  BOLT
09168-08016  GASKET (8.2X14X1)
09248-10010  PLUG, OIL GALLERY
09168-10002  GASKET (9.9X14X0.3)
09248-16012  PLUG, OIL GALLERY (16X8)
09168-16002  GASKET (16X22X2)
09248-14005  PLUG (14X12) | MODEL X/Y
09248-14005  PLUG (14X12) | MODEL K1
09248-14005 !  PLUG, SHAFT | MODEL K2/K3
09168-14011  GASKET (14X20X1.5) | MODEL X
09168-14004 !  GASKET | MODEL Y
09168-14004 !  GASKET | MODEL K1/K2/K3
16591-06B01 !  UNION, OIL FILTER
12228-24F00-0D0  BEARING, CRANK THRUST (GREEN) | RH SEE ILLUSTRATION ON FIG.7(C-3)
12228-24F00-0A0  BEARING, CRANK THRUST (RED) | LH SEE ILLUSTRATION ON FIG.7(C-3)
12228-24F00-0B0  BEARING, CRANK THRUST (BLACK)
12228-24F00-0C0  BEARING, CRANK THRUST (BLUE)
12228-24F00-0D0  BEARING, CRANK THRUST (GREEN)
12228-24F00-0E0  BEARING, CRANK THRUST (YELLOW)
12228-24F00-0F0  BEARING, CRANK THRUST (WHITE)
16510-07J00 !  FILTER ASSY, ENG OIL M20
09100-12076  BOLT (12X320) | MODEL X/Y/K1
09103-12066  BOLT (12X320) | MODEL K2/K3
09100-12075  BOLT (12X240) | MODEL X/Y/K1
09103-12067  BOLT (12X240) | MODEL K2/K3
09159-12054  NUT
11611-24F00  SPACER, ENGINE MOUNT
08322-01127  WASHER | MODEL X/Y/K1
37820-33D10 !  SWITCH, OIL PRESSURE | MODEL X/Y
37820-33D10  SWITCH ASSY, OIL PRESSURE | MODEL K1/K2/K3
11340-24F01 !  COVER, CLUTCH | MODEL X
11340-24F01  COVER, CLUTCH | MODEL Y/K1/K2/K3; Includes Item(s) 2
11971-33210  LENS, OIL LEVEL
11482-24F00  GASKET, CLUTCH COVER
04211-09189  PIN
01547-06307  BOLT | MODEL X
09103-06213  BOLT (6X30) | MODEL Y/K1/K2/K3
09259-20008-XC0 !  PLUG, GEAR OIL FILLER | MODEL X/Y/K1/K2
11971-25D00  PLUG, ENGINE OIL FILLER | MODEL K3
09280-17003  O RING (D:3.1,ID:16.8)
11371-24F00  COVER, CLUTCH OUTER
11372-24F00  CUSHION, CLUTCH OUTER COVER
09139-06107  SCREW
11373-24F00  WASHER, CL OUTER COVER SCREW
11380-24F01  COVER, STARTER CLUTCH | MODEL X/Y/K1/K2
11380-24F20  COVER, STARTER CLUTCH | MODEL K3
11491-24F01 !  GASKET, STARTER CLUTCH COVER | MODEL X
11491-24F01  GASKET, STARTER CLUTCH COVER | MODEL Y/K1/K2/K3
04211-09149  PIN
01547-06257  BOLT | MODEL X
09103-06212  BOLT (6X25) | MODEL Y/K1/K2/K3
01547-06357  BOLT | MODEL X
09103-06214  BOLT (6X35) | MODEL Y/K1/K2/K3
09168-06023  GASKET
09259-36016-20H  PLUG, SHAFT HOLE | MODEL X/Y/K1
09259-36021  PLUG, SHAFT HOLE | MODEL K2/K3
09280-33004  O RING (D:3.1,ID:32.7)
09248-16012  PLUG, TDC (16X8)
09168-16002  GASKET
11382-24F00  CAP, STARTER IDLE GEAR | MODEL X/Y/K1/K2
11382-24F20  CAP, STARTER IDLE GEAR | MODEL K3
11492-24F00  GASKET, STARTER IDLE GEAR CAP
04211-09149  PIN
01547-06257  BOLT | MODEL X
09103-06212  BOLT (6X25) | MODEL Y/K1/K2/K3
01547-06357  BOLT | MODEL X
09103-06214  BOLT (6X35) | MODEL Y/K1/K2/K3
11351-24F00  COVER, MAGNETO
11483-24F00  GASKET, MAGNETO COVER
04211-09149  PIN
01547-06307  BOLT | MODEL X
09103-06213  BOLT (6X30) | MODEL Y/K1/K2/K3
11361-24F00  COVER, ENGINE SPROCKET | MODEL X
11361-24F10  COVER, ENGINE SPROCKET | MODEL Y/K1/K2/K3
11362-24F00  PROTECTOR, ENGINE SPRKT COVER
04211-09149  PIN
01547-06407  BOLT | MODEL X
09103-06215  BOLT (6X40) | MODEL Y/K1/K2/K3
01547-06557  BOLT | MODEL X
09103-06216  BOLT (6X55) | MODEL Y/K1/K2/K3
11383-24F00  COVER, GEAR SHIFT
11485-24F00  GASKET, GEAR SHIFT COVER
04211-09149  PIN
01547-0625B !  BOLT
01547-0635B !  BOLT
11330-24F01  COVER, BREATHER
09364-12002  UNION, BREATHER
11318-24F01 !  GASKET, BREATHER COVER | MODEL X
11318-24F01  GASKET, BREATHER COVER | MODEL Y/K1/K2/K3
01547-0630B !  BOLT, SEC CASE | MODEL X
01547-0630B !  BOLT, SEC CASE | MODEL Y/K1/K2/K3
01547-0650B !  BOLT | MODEL X
11334-24F00  BRACKET, OIL RETURN TANK | MODEL X
11330-02F01  TANK, OIL RETURN | MODEL X
01550-0612A !  BOLT, REAR COMB BRACKET | MODEL X
11332-24F00  HOSE, BREATHER | MODEL X
09401-15101  CLIP | MODEL X
11390-24F00  HOSE, OIL DRAIN | MODEL X
09403-16307  CLAMP, OIL DRAIN HOSE | MODEL X
12160-24F02 !  ROD ASSY, CONNECTING | MODEL X
12160-24F02  ROD ASSY, CONNECTING | MODEL Y/K1/K2/K3; Includes Item(s) 2 - 2A
12163-24F00  BOLT
12165-27A50  PIN, CONNROD
12164-46E01-0A0  BEARING, CRANK PIN (GREEN) | *SEE NOTE
12164-46E01-0B0  BEARING, CRANK PIN (BLACK) | *SEE NOTE
12164-46E01-0C0  BEARING, CRANK PIN (BROWN) | *SEE NOTE
12164-46E01-0D0  BEARING, CRANK PIN (YELLOW) | *SEE NOTE
12000-24820  CRANKSHAFT SET | Includes Item(s) 5 - 6
12228-24F00-0D0  BEARING, THRUST RH (GREEN)
12228-24F00-0A0  BEARING, THRUST LH (RED)
12228-24F00-0B0  BEARING, THRUST LH (BLACK)
12228-24F00-0C0  BEARING, THRUST LH (BLUE)
12228-24F00-0D0  BEARING, THRUST LH (GREEN)
12228-24F00-0E0  BEARING, THRUST LH (YELLOW)
12228-24F00-0F0  BEARING, THRUST LH (WHITE)
12229-24F00-0A0  BEARING, CRANKSHAFT (GREEN) | *SEE NOTE
12229-24F00-0B0  BEARING, CRANKSHAFT (BLACK) | *SEE NOTE
12229-24F00-0C0  BEARING, CRANKSHAFT (BROWN) | *SEE NOTE
12229-24F00-0D0  BEARING, CRANKSHAFT (YELLOW) | *SEE NOTE
12111-24F11-0F0  PISTON
12140-24F10 !  RING SET, PISTON | MODEL X
12140-24F10  RING SET, PISTON | MODEL Y/K1/K2/K3
12151-24F10  PIN, PISTON
09381-20004  CIRCLIP
12731-24F00  SPROCKET, CAM CHAIN
11210-24F00-0F0 !  CYLINDER | MODEL X/Y
11210-24F00-0F0  CYLINDER | MODEL K1/K2/K3
11241-15H00 !  GASKET, CYLINDER
01421-0625A !  STUD BOLT
08316-1006B !  NUT
04211-11169  PIN
11280-24F00  PIPE, CRANKCASE OIL
11282-24F00  HOSE, OIL
09360-10062 !  BOLT, UPPER
09168-10007  GASKET
09360-14012  BOLT, OIL PIPE UNION
09280-12012  O RING, OIL PIPE
09106-06073  BOLT, OIL PIPE (6X16)
09168-14015  GASKET, OIL PIPE (14X20X1.5)
11283-24F00  CUSHION, CRANKCASE OIL PIPE
11100-24F00  HEAD ASSY, CYLINDER | Includes Item(s) 2 - 4
09103-06026  BOLT (6X39)
09103-06165  BOLT (6X45)
09206-08007  PIN
11115-14D71  GUIDE, VALVE (OS:0.3) | OPT
11141-24F00  GASKET, CYLINDER HEAD
04211-11169  PIN
01550-0630A !  BOLT
09103-10276  BOLT (10X175)
09160-10082  WASHER
07120-0612B !  PLUG
07120-0650B !  BOLT, RECTIFIER
09168-06023  GASKET
11131-33E01 !  PIPE, OIL
01550-0635A !  BOLT
01550-0645A !  BOLT (6X45)
08322-0106B !  WASHER
09482-00458  SPARK PLUG (NGK,CR9E)
09482-00459  SPARK PLUG (DENSO,U27ESR-N)
09482-00456  SPARK PLUG (NGK,CR8E) | OPT
09482-00460  SPARK PLUG (NGK,CR10E) | OPT
09482-00457  SPARK PLUG (DENSO,U24ESR-N) | OPT
09482-00461  SPARK PLUG (DENSO,U31ESR-N) | OPT
13111-24F00  PIPE, INTAKE NO.1
09402-60208  CLAMP
13170-24F02 !  CLAMP,INTAKE PI | MODEL X/Y
13170-24F02 !  CLAMP,INTAKE PI | MODEL K1/K2/K3
07120-1045B !  BOLT
07120-1055B !  BOLT
11161-33E00  BOLT, CYL HEAD SIDE FACE
11191-13E00  WASHER
13650-51G10  SENSOR, WATER TEMPERATURE | MODEL X/Y/K1/K2
13650-10G00  SENSOR, WATER TEMPERATURE | MODEL K3
09168-12017  GASKET
11171-24F00  COVER, CYLINDER HEAD
11173-24F00  GASKET, HEAD COVER NO.1
11178-33E00  GASKET, HEAD COVER NO.2
09106-07021 !  BOLT (7X17.5)
09161-11008  WASHER
04221-08149  PIN
31800-26E00  RELAY ASSY, STARTING | Includes Item(s) 2 - 3
31861-26E00  COVER, RELAY ASSY
09481-30101  FUSE, 30A
09128-06013  BOLT (6X8)
32800-33E21 !  RECTIFIER ASSY | MODEL X/Y/K1
32800-33E21 !  RECTIFIER ASSY | MODEL K2/K3
32811-24F00  BRACKET, RECTIFIER
09116-06025  SCREW (6X25)
09169-06064  SPACER
09320-08066 !  CUSHION
02142-0620A !  SCREW
08316-1006B !  NUT
32160-02F00  SENSOR ASSY, CAM POSITION | MODEL X/Y/K1
32160-02F10  SENSOR ASSY, CAM POSITION | MODEL K2/K3; Includes Item(s) 13
32161-02F00  PACKING
07130-0616A !  BOLT, SENSOR
33410-24F00  COIL ASSY, IGNITION | MODEL X/Y/K1
33410-24F10  COIL ASSY, IGNITION | MODEL K2/K3
32920-24F21  CONTROL UNIT, FI | MODEL X/Y ?32920-24F20
32920-24FD0  CONTROL UNIT, FI | MODEL K1
32920-24FK0  CONTROL UNIT, FI | MODEL K2/K3
33651-12910  BAND, EPI CONT
33652-05300  CUSHION (40X40X16) | CUT AS REQUIRED PROFILE (20X40)
33960-02F00  SENSOR ASSY, FUEL CUT
44400-19810 !  HOSE SET,TANK &
09440-13041  SPRING
09401-11413  CLIP
44240-17C00  VALVE, BREATHER
44890-24F00  PLATE, BREATHER VALVE | Includes Item(s) 6
44894-24A00  CUSHION
02142-0610A !  SCREW
44892-24A00  PLATE, VALVE NO.2 | Includes Item(s) 9
44894-24A00  CUSHION
02142-0408B !  SCREW
09355-54116-600  HOSE, 2 WAY VALVE & BREATHER VALVE | L:600!320
09440-13051  SPRING
44240-24F00  VALVE, 2 WAY & CANISTER
09160-06077  WASHER
01550-0616A !  BOLT
17210-26E00  CANISTER
09251-07003  CAP
44883-26E00  CUSHION, CANISTER
44880-24F00  BRACKET, CANISTER
01550-0612A !  BOLT, REAR COMB BRACKET
44882-26E00  HOLDER, CANISTER
02142-0610A !  SCREW
09355-54116-600  HOSE, CANISTER & 2 WAY VALVE | L:600!130
09440-13041  SPRING
09359-54111-600  HOSE, CANISTER & CARB
09440-13053  SPRING
09401-12404  CLIP
09364-06005  UNION
43510-24F00  BRACKET, FRONT FOOTREST RH
43521-24F00  BRACKET, FRONT FOOTREST LH
09106-08147 !  BOLT | MODEL X
09319-08036  BUSH | MODEL X
09161-12010  WASHER | MODEL X
09106-08147  BOLT, BRACKET | MODEL Y/K1/K2/K3
09161-13004  WASHER, OUTER | MODEL Y/K1/K2/K3
09161-17002  WASHER, INNER | MODEL Y/K1/K2/K3
09319-08045  BUSH | MODEL Y/K1/K2/K3
43531-24F00  BAR, FRONT FOOTREST RH
43541-24F00  BAR, FRONT FOOTREST LH
43550-24F00  RUBBER
09208-08016  PIN
08332-1106A !  CIRCLIP
09448-18022  SPRING
43536-31E01  BALANCER | MODEL X/Y
43536-31E20  BALANCER | MODEL K1/K2/K3
02142-0525B !  SCREW | MODEL X/Y
02142-05353  SCREW, INNER | MODEL K1/K2/K3
02142-0520B !  SCREW, KNOB | MODEL X/Y
02142-0525B !  SCREW | MODEL K1/K2/K3
43576-48B02  BOLT, BANK SENS0R RH
43576-48B20  BOLT, BANK SENSOR LH
43600-24F00  FOOTREST ASSY, PILLION RH
43700-24F00  FOOTREST ASSY, PILLION LH | Includes Item(s) 23 - 30
43610-33E11 !  BAR, PILLION RH | MODEL X/Y
43610-33E11  BAR, PILLION RH | MODEL K1/K2/K3
43620-33E11 !  BAR, PILLION LH | MODEL X/Y
43620-33E11  BAR, PILLION LH | MODEL K1/K2/K3
09208-06007  PIN
09440-05005  SPRING
06111-07004  BALL
43816-33E21  PLATE, RH
43826-33E22 !  PLATE, LH | MODEL X/Y/K1
43826-33E22  PLATE, LH | MODEL K2/K3
08332-1104A !  E RING
09106-08121  BOLT, BRACKET
41100-24F04 !  NO DESCRIPTION AVAILABLE | MODEL X
41100-24F04 !  NO DESCRIPTION AVAILABLE | MODEL Y
41100-24F04 !  NO DESCRIPTION AVAILABLE | GSX1300R K1/K2/K3
41100-24F12-291  FRAME (BLACK) | GSX1300RZK2 E3,E33
41100-24F21-291 !  NO DESCRIPTION AVAILABLE | GSX1300RZK3 E3,E28,E33
43585-33E00  CAP, TANK RAIL
41200-24F00  RAIL, SEAT | MODEL X/Y
41200-24F10  RAIL, SEAT | MODEL K1/K2/K3
09103-10296  BOLT, SEAT RAIL
46315-24F01 !  HOOK, SEAT RAIL | MODEL X
46315-24F01  HOOK, SEAT RAIL | MODEL Y/K1/K2/K3
09250-05009  CAP
41911-33E10  SPACER, ENGINE MOUNT
09106-08105  BOLT, SPACER
41921-19F11 !  BOLT, CRANKCASE ADJUST | MODEL X
41921-19F11  BOLT, CRANKCASE ADJUST | MODEL Y/K1/K2/K3
41921-33E11  BOLT, CRANKCASE ADJUST
41922-19F12 !  NUT, CRANK CASE ADJUST | MODEL X
41922-19F12 !  NUT, CRANK CASE ADJUST | MODEL Y/K1/K2/K3
41922-33E30 !  NUT, CRANK CASE ADJUST
41860-24F00  PAD, TANK RAIL RH
41960-24F00  PAD, TANK RAIL LH
41850-24F00  EMBLEM, FRAME BODY RH | OPT
41950-24F00  EMBLEM, FRAME BODY LH | OPT
47110-24F20-1LF  COVER, FRAME (BLUE) | FOR CN5
47110-24F20-33J  COVER, FRAME (BLACK) | FOR FH5
47110-24F20-YC6  COVER, FRAME (RED) | FOR FH6; Includes Item(s) 2 - 3
68131-24F10-CN8  EMBLEM | FOR 1LF
68131-24F10-FJ7  EMBLEM | FOR 33J
68131-24F10-FJ8  EMBLEM | FOR YC6
68641-14F30-M5P  EMBLEM, in.SUZUKIin. | FOR 1LF
68641-14F30-F3H  EMBLEM, in.SUZUKIin. | FOR 33J
68641-14F30-FJ6  EMBLEM, in.SUZUKIin. | FOR YC6
47511-24F10  CAP, RH
47521-24F00  CAP, LH
09409-06314-5PK  CLIP, LH (BLACK)
03541-0412A !  SCREW (4x12)
09139-06126 !  SCREW
09320-09016  CUSHION
47161-27E00  CUSHION, REAR
09136-06105  SCREW, UPPER
09180-06288  SPACER
09320-10045  CUSHION
09409-06314-5PK  CLIP, LOWER (BLACK)
47311-24F00-1LF  COVER, CENTER (BLUE) | FOR CN5
47311-24F00-33J  COVER, CENTER (BLACK) | FOR FH5
47311-24F00-YC6  COVER, CENTER (RED) | FOR FH6
47191-24F00  CUSHION, UPPER FRONT
47191-24F30  CUSHION, PILLION RIDER HDL, RR
47190-24F21 !  WASHER, UPPER REAR
09409-06314-5PK  CLIP (BLACK)
47191-24F20  CUSHION, CENTER
47110-24F20-3TX  COVER, FRAME (BLUE) | GSX1300RK2 FOR CN5
47110-24F20-2AX  COVER, FRAME (BLACK) | GSX1300RK2 FOR FH9
47110-24F30-YM6  COVER, FRAME (SILVER) | GSX1300RK2 FOR HE6
47110-24F40-019  COVER, FRAME (BLACK) | GSX1300RZK2 FOR 019; Includes Item(s) 2 - 3
68131-24F10-HT1  EMBLEM | GSX1300RK2 FOR 3TX
68131-24F10-HT2  EMBLEM | GSX1300RK2 FOR 2AX
68131-24F00-HT3  EMBLEM | GSX1300RK2 FOR YM6
68131-24F20-JB6  EMBLEM | GSX1300RZK2 FOR 019
68641-14F30-M5P  EMBLEM, in.SUZUKIin. | GSX1300RK2 FOR 3TX
68641-14F30-HT4  EMBLEM, in.SUZUKIin. | GSX1300RK2 FOR 2AX
68281-24F10-019 !  EMBLEM (BLACK) | GSX1300RK2 FOR YM6
68641-24F00-JB5  EMBLEM, in.SUZUKIin. (BLACK) | GSX1300RZK2 FOR 019
47511-24F10  CAP, RH
47521-24F00  CAP, LH
09409-06314-5PK  CLIP, LH (BLACK)
03541-0412A !  SCREW (4x12)
09139-06126 !  SCREW
09320-09016  CUSHION
47161-27E00  CUSHION, REAR
09136-06105  SCREW, UPPER
09180-06288  SPACER
09320-10045  CUSHION
09409-06314-5PK  CLIP, LOWER (BLACK)
47311-24F00-1LF  COVER, CENTER (BLUE) | GSX1300RK2 FOR CN5
47311-24F00-33J  COVER, CENTER (BLACK) | GSX1300RK2 FOR FH9
47311-24F00-YM6  COVER, CENTER (SILVER) | GSX1300RK2 FOR HE6
47311-24F10-019  COVER, CENTER (BLACK) | GSX1300RZK2 FOR 019
47191-24F00  CUSHION, UPPER FRONT
47191-24F30  CUSHION, PILLION RIDER HDL, RR
47190-24F21 !  WASHER, UPPER REAR
09409-06314-5PK  CLIP (BLACK)
47191-24F20  CUSHION, CENTER
94401-24F60-CN5  COWLING ASSY, BODY | GSX1300RK3
94401-24F60-KT7  COWLING ASSY, BODY | GSX1300RK3
94401-24F70-LA1  COWLING ASSY, BODY | GSX1300RK3
94401-24F40-019  COWLING ASSY, BODY (BLACK) | GSX1300RZK3 E28
94401-24F70-YAV  COWLING ASSY, BODY (ORANGE) | GSX1300RZK3 E3,E33; Includes Item(s) 2 - 3
68281-24F10-CN5  EMBLEM | GSX1300RK3 FOR CN5
68281-24F10-KT7  EMBLEM | GSX1300RK3 FOR KT7
68281-24F20-GW5  EMBLEM | GSX1300RK3 FOR LA1
68281-24F20-MZ6  EMBLEM | GSX1300RZK3 E3,E33 FOR YAV
68641-24F00-JB5  EMBLEM | GSX1300RZK3 E28 FOR 019
94611-24F00  WINDSCREEN
09139-05025  SCREW
08322-0105A !  WASHER, FRONT
09159-05019  NUT
94641-24F00  PANEL, UPPER RH
94651-24F00  PANEL, UPPER LH
94419-24F00  COVER, BODY COWL
47110-24F01-Y9K !  NO DESCRIPTION AVAILABLE | FOR M9S
47111-24F01 !  COVER,FRAME PRI | FOR M9T; Includes Item(s) 2 - 2
68131-24F00-N0Z  EMBLEM | FOR Y9K
68131-24F00-N1D  EMBLEM | FOR Y7L
47511-24F00  CAP, RH
47511-24F10  CAP, RH | E33
47521-24F00  CAP, LH
09409-06314-5PK  CLIP, LH (BLACK)
03541-0412A !  SCREW (4x12)
09139-06126 !  SCREW
09320-09016  CUSHION
47161-27E00  CUSHION, REAR
09136-06105  SCREW, UPPER
09180-06288  SPACER
09320-10045  CUSHION
09409-06314-5PK  CLIP, LOWER (BLACK)
47311-24F00-Y9K  COVER, CENTER (BROWN) | FOR M9S
47311-24F00-Y7L  COVER, CENTER (BLACK) | FOR M9T
47191-24F00  CUSHION, UPPER REAR
47190-24F01 !  WASHER
09409-06314-5PK  CLIP (BLACK)
47191-24F20  CUSHION, CENTER
47110-24F10-YC6  COVER, FRAME (RED) | FOR CN4
47110-24F10-1LF  COVER, FRAME (BLUE) | FOR CN5
47110-24F10-Y7L  COVER, FRAME (BLACK) | E28 FOR M9T; Includes Item(s) 2 - 2
68131-24F10-CN7  EMBLEM | FOR YC6
68131-24F10-CN8  EMBLEM | FOR 1LF
68131-24F10-CN6  EMBLEM | FOR Y7L
47511-24F10  CAP, RH
47521-24F00  CAP, LH
09409-06314-5PK  CLIP, LH (BLACK)
03541-0412A !  SCREW (4x12)
09139-06126 !  SCREW
09320-09016  CUSHION
47161-27E00  CUSHION, REAR
09136-06105  SCREW, UPPER
09180-06288  SPACER
09320-10045  CUSHION
09409-06314-5PK  CLIP, LOWER (BLACK)
47311-24F00-YC6  COVER, CENTER (RED) | FOR CN4
47311-24F00-1LF  COVER, CENTER (BLUE) | FOR CN5
47311-24F00-Y7L  COVER, CENTER (BLACK) | E28 FOR M9T
47191-24F00  CUSHION, UPPER REAR
47190-24F01 !  WASHER
09409-06314-5PK  CLIP (BLACK)
47191-24F20  CUSHION, CENTER
59600-24F00  CYLINDER ASSY, FRONT MASTER | Includes Item(s) 2 - 10
59600-45860  PISTON/CUP SET
59666-44300  BOOT
59664-48B00  PROTECTOR
59667-49460  DIAPHRAGM
59668-41C00  PLATE
59669-41C00  CAP
69689-49300  SCREW
59671-36500  HOLDER
59675-02FA0  BOLT (6X22)
09360-10062 !  BOLT, UPPER
09360-10062 !  BOLT, UPPER
09360-10064 !  BOLT, FR CALIPER
09161-10009  WASHER (10X15X1.5)
59480-24F02 !  HOSE COMP,FRONT | MODEL X
59480-24F02 !  HOSE COMP,FRONT | MODEL Y/K1/K2/K3
59240-24F02 !  HOSE COMP,FRONT | MODEL X
59240-24F02 !  HOSE COMP,FRONT | MODEL Y/K1/K2/K3
59266-38D00  CLAMP, BRAKE HOSE NO.1
59268-33E01  GUIDE, BRAKE HOSE NO.1
01550-0616A !  BOLT
09403-14304  CLAMP, BRAKE HOSE NO.2
59302-33860 !  PAD & SHIM SET | GSX1300RK3
59300-33E40-999 !  CALIPER ASSY, FRONT LH | GSX1300RK3
59100-33E11-999 !  CALIPER ASSY, F | GSX1300RZK3
59300-33E11-999 !  CALIPER ASSY,FR | GSX1300RZK3; Includes Item(s) 1 - 11
59301-33861  PISTON SET
59300-33881  SEAL SET, PISTON
59301-33870  PAD SET
69141-46E01  PIN
69142-45000  CLIP
59145-33E00 !  BOLT
59151-46E00  COVER
59153-22D00  SCREW
59121-18410  BLEEDER
55156-66310  CAP
59171-33E00  SHIM
09103-10320  BOLT (10X30)
59100-33E11-999 !  CALIPER ASSY, F | MODEL X
59300-33E11-999 !  CALIPER ASSY,FR | MODEL X
59100-33E11-999 !  CALIPER ASSY, F | MODEL Y/K1/K2
59300-33E11-999 !  CALIPER ASSY,FR | MODEL Y/K1/K2; Includes Item(s) 1 - 11
59301-33861 !  PISTON SET
59300-33881 !  SEAL SET, PISTON
59301-33870  PAD SET
69141-46E01  PIN
69142-45000  CLIP
59145-33E00  BOLT | MODEL X
59145-33E00 !  BOLT | MODEL Y/K1/K2
59151-46E00  COVER
59153-22D00  SCREW
59121-18410  BLEEDER
55156-66310  CAP
59171-33E00  SHIM
09103-10296  BOLT (10X30) | MODEL X
09103-10320  BOLT (10X30) | MODEL Y/K1/K2
53110-24F00-Y9K  FENDER, FRONT (BROWN) | MODEL X FOR M9S
53110-24F00-Y7L  FENDER, FRONT (BLACK) | MODEL X FOR M9T
53110-24F00-YC6  FENDER, FRONT (RED) | MODEL Y FOR CN4
53110-24F00-1LF  FENDER, FRONT (BLUE) | MODEL Y/K1 FOR CN5
53110-24F00-Y7L  FENDER, FRONT (BLACK) | MODEL Y E28 FOR M9T
53110-24F00-YAY !  FENDER, FRONT (BLACK) | MODEL K1 FOR FH5
53110-24F00-YC6  FENDER, FRONT (RED) | MODEL K1 FOR FH6
53110-24F00-1LF  FENDER, FRONT (BLUE) | GSX1300RK2 FOR CN5
53110-24F00-YAY !  FENDER, FRONT (BLACK) | GSX1300RK2 FOR FH9
53110-24F00-YM6  FENDER, FRONT (SILVER) | GSX1300RK2 FOR HE6
53110-24F10-019  FENDER, FRONT (BLACK) | GSX1300RZK2 E3,E33 FOR 019
53110-24F00-1LF  FENDER, FRONT (BLUE) | GSX1300RK3 FOR CN5
53110-24F00-YAY !  FENDER, FRONT (BLACK) | GSX1300RK3 FOR KT7
53110-24F00-YU8  FENDER, FRONT (GRAY) | GSX1300RK3 FOR LA1
53110-24F10-019  FENDER, FRONT (BLACK) | GSX1300RZK3 E28 FOR 019
53110-24F00-YAV  FENDER, FRONT (ORANGE) | GSX1300RZK3 E3,E33 FOR YAV
09139-06030  SCREW, REAR (L:16)
09161-06021  WASHER, REAR
51103-24F00  DAMPER ASSY, FRONT FORK RH | MODEL X/Y/K1/K2
51103-24F30  DAMPER ASSY, FRONT FORK RH | MODEL K3
51104-24F00  DAMPER ASSY, FRONT FORK LH | MODEL X/Y/K1/K2
51104-24F30  DAMPER ASSY, FRONT FORK LH | MODEL K3; Includes Item(s) 1 - 15
51110-24F00  TUBE, INNER RH | MODEL X/Y/K1/K2
51110-24F30  TUBE, INNER RH | MODEL K3
51120-24F00  TUBE, INNER LH | MODEL X/Y/K1/K2
51120-24F30  TUBE, INNER LH | MODEL K3
51158-14200  WASHER
51153-02FA0  SEAL, OIL
51156-14200  RING, STOPPER
51173-02FA0  SEAL, DUST
51146-24F00  CYLINDER
51147-40C00  BOLT
51148-40300  GASKET
51129-24F00  NUT
51171-24F00  SPRING, FRONT
51158-24F00  GUIDE, SPRING
51176-24F00  SPACER, SPRING
51130-24F00  TUBE, OUTER (GOLD) | MODEL X/Y/K1/K2
51130-24F20 !  TUBE, OUTER (BRONZE) | MODEL K3
51351-24F00  CAP, FRONT FORK
51166-24F30 !  BOLT
51166-24F30  BOLT | MODEL K3
54111-33E11-35W !  NO DESCRIPTION AVAILABLE | GSX1300RX/Y/K1/K2
54111-33E11-019 !  WHEEL, FRONT (17XMT3.50) (BLACK) | GSX1300RZK2 GSX1300RK3
54731-33E10  SPACER, HUB BEARING
09262-25061  BEARING (25X52X15)
09285-32004  SEAL (32X52X7)
54711-33E00  AXLE, FRONT | MODEL X/Y/K1
54711-42F00  AXLE, FRONT | MODEL K2/K3
54712-33E00  NUT, AXLE
59210-33E50  DISC, FRONT BRAKE (GOLD/BLACK) | GSX1300RX/Y/K1/K2
59210-33EA1 !  DISC,FRONT BRAK | GSX1300RZK2/RK3
09106-08148 !  BOLT, DISC | MODEL X
09106-08148  BOLT (8X33) | MODEL Y/K1/K2/K3
55110-24F00  TIRE, FRONT 120/70 ZR17(58W),BRIDGESTONE
43130-24A00  VALVE ASSY, WHEEL RIM (TR412)
55411-00A00 !  BALANCER (10G)
55412-17G00 !  BALANCER, WHEEL, NO.2
44300-24F03  COCK ASSY, FUEL | Includes Item(s) 2
44351-33E00  O RING, JOINT
09128-06057  BOLT
09168-06026  GASKET
44433-24F00  HOSE, FUEL | MODEL X
44433-24F00 !  HOSE, FUEL | MODEL Y
09401-13417  CLIP
09440-17020-XC0 !  SPRING
09251-09005  PLUG, FUEL OUT PIPE
09404-06434  CLAMP | MODEL X
34800-24810  GAUGE SET, FUEL LEVEL | MODEL X; Includes Item(s) 11 - 12
34820-24810  GASKET SET | MODEL X
09106-05024-XC0 !  BOLT,5X8 | MODEL X
34800-24820  GAUGE SET, FUEL LEVEL | MODEL Y; Includes Item(s) 14
34825-31F00  O RING | MODEL Y
08319-2106B !  NUT | MODEL Y
09160-06128  WASHER | MODEL Y
44100-24F30-CN5  TANK ASSY, FUEL
44100-24F30-FH5  TANK ASSY, FUEL
44100-24F30-FH6  TANK ASSY, FUEL
44100-24F40-CN5  TANK ASSY, FUEL | E33
44100-24F40-FH5  TANK ASSY, FUEL | E33
44100-24F40-FH6  TANK ASSY, FUEL | E33; Includes Item(s) 2
68111-24F00-0MT  EMBLEM (SILVER)
44201-33810  CAP SET, FUEL TANK
44200-33890  CAP SET, FUEL TANK | E33
09106-05017  BOLT
44191-24F10  SHIELD, HEAT
09139-06029  BOLT, FRONT
09160-06036  WASHER
09320-09009  CUSHION
09169-06062  SPACER
44533-24F00  COVER, SIDE RH
44543-24F00  COVER, SIDE LH
44540-24F10  PLATE, SIDE
02142-0610A !  SCREW
44560-24F01 !  BRACKET, TANK
09116-06152  BOLT
09320-08001  CUSHION
09169-06062  SPACER
44541-24F00  CUSHION, JOINT
44561-33E10  SPACER
01550-0895A !  BOLT
44574-33E01  STAY
09403-05310  CLIP
44550-24F00  BRACKET, REAR
01550-0812A !  PLUG, OIL DRAIN
44423-24F00  HOSE, BREATHER
09352-70113-600  HOSE, DRAIN | L:600!500
09404-06432  CLAMP, DRAIN HOSE
44534-24F00  CUSHION, FRONT
44534-24F00 !  CUSHION, FRONT
44271-24F00  SHEET, HEAT SHIELD RUBBER
09407-18402  CLAMP
09409-06322-5PK  CLIP (BLACK)
44100-24F30-YZX  TANK ASSY, FUEL | GSX1300RK2
44100-24F30-FH9  TANK ASSY, FUEL | GSX1300RK2
44100-24FB0-HE6  TANK ASSY, FUEL | GSX1300RK2
44110-24F30-13L !  TANK ASSY,FUEL( | GSX1300RZK2
44100-24F40-YZX  TANK ASSY, FUEL | E33
44100-24F40-FH9  TANK ASSY, FUEL | E33
44100-24F90-HE6  TANK ASSY, FUEL | E33; Includes Item(s) 2 - 2
68111-24F00-YC8  EMBLEM (BLACK) | GSX1300RK2 FOR YZX
68111-24F00-YY3  EMBLEM (CHROME) | GSX1300RK2 FOR FH9
68111-24F10-20G  EMBLEM (GRAY) | GSX1300RK2 FOR HE6
68111-24F00-YS7  EMBLEM (BLACK) | GSX1300RZK2 FOR 019
44201-33810  CAP SET, FUEL TANK
44200-33890  CAP SET, FUEL TANK | E33
09106-05017  BOLT
44191-24F10  SHIELD, HEAT
09139-06029  BOLT, FRONT
09160-06036  WASHER
09320-09009  CUSHION
09169-06062  SPACER
44533-24F00  COVER, SIDE RH
44543-24F00  COVER, SIDE LH
44540-24F10  PLATE, SIDE
02142-0610A !  SCREW
44560-24F01 !  BRACKET, TANK
09116-06152  BOLT
09320-08001  CUSHION
09169-06062  SPACER
44541-24F00  CUSHION, JOINT
44561-33E10  SPACER
01550-0895A !  BOLT
44574-33E01  STAY
09403-05310  CLIP
44550-24F00  BRACKET, REAR
01550-0812A !  PLUG, OIL DRAIN
44423-24F00  HOSE, BREATHER
09352-70113-600  HOSE, DRAIN | L:600!500
09404-06432  CLAMP, DRAIN HOSE
44534-24F00  CUSHION, FRONT
44534-24F00 !  CUSHION, FRONT
44271-24F00  SHEET, HEAT SHIELD RUBBER
09407-18402  CLAMP
09409-06322-5PK  CLIP (BLACK)
44100-24FC0-CN5  TANK ASSY, FUEL | GSX1300RK3 E3,E28
44100-24FC0-KT7  TANK ASSY, FUEL | GSX1300RK3 E3,E28
44100-24FC0-LA1  TANK ASSY, FUEL | GSX1300RK3 E3,E28
44110-24F30-13L !  TANK ASSY,FUEL( | GSX1300RZK3 E28
44100-24FD0-CN5  TANK ASSY, FUEL | GSX1300RK3 E33
44100-24FD0-KT7  TANK ASSY, FUEL | GSX1300RK3 E33
44100-24FD0-LA1  TANK ASSY, FUEL | GSX1300RK3 E33
44100-24FA0-YAV  TANK ASSY, FUEL (ORANGE) | GSX1300RZK3 E3
44100-24FH0-YAV  TANK ASSY, FUEL (ORANGE) | GSX1300RZK3 E33; Includes Item(s) 2 - 2
68111-24F00-0AT  EMBLEM (CHROME) | GSX1300RK2 FOR CN5,KT7
68111-24F00-YN7  EMBLEM (BLACK) | GSX1300RK2 FOR LA1
68111-24F00-YS7  EMBLEM (BLACK) | GSX1300RZK3 E28
68111-24F00-YC8  EMBLEM (BLACK) | GSX1300RZK3 E3,E33
44201-33810  CAP SET, FUEL TANK | E3,E28
44200-33890  CAP SET, FUEL TANK | E33
09106-05017  BOLT
44191-24F10  SHIELD, HEAT
09139-06029  BOLT, FRONT
09160-06036  WASHER
09320-09009  CUSHION
09169-06062  SPACER
44533-24F00  COVER, SIDE RH
44543-24F00  COVER, SIDE LH
44540-24F10  PLATE, SIDE
02142-0610A !  SCREW
44560-24F01 !  BRACKET, TANK
09116-06152  BOLT
09320-08001  CUSHION
09169-06062  SPACER
44541-24F00  CUSHION, JOINT
44561-33E10  SPACER
01550-0895A !  BOLT
44574-33E01  STAY
09403-05310  CLIP
44550-24F00  BRACKET, REAR
01550-0812A !  PLUG, OIL DRAIN
44423-24F00  HOSE, BREATHER
09352-70113-600  HOSE, DRAIN | L:600!500
09404-06432 !  CLAMP (L:65)
44534-24F00  CUSHION, FRONT
44534-24F00 !  CUSHION, FRONT
44271-24F00  SHEET, HEAT SHIELD RUBBER
09407-18402  CLAMP
09409-06322-5PK  CLIP (BLACK)
44100-24F02-M9S !  TANK ASSY,FUEL
44100-24F02-M9T !  TANK ASSY, FUEL
44100-24F12-M9S !  NO DESCRIPTION AVAILABLE | E33
44100-24F12-M9T !  TANK ASSY,FUEL | E33; Includes Item(s) 2 - 2
68111-32B10-29F  EMBLEM (BROWN) | FOR M9S
68111-32B10-Y7L  EMBLEM (BLACK) | FOR M9T
44201-33810  CAP SET, FUEL TANK
44200-33890  CAP SET, FUEL TANK | E33
09106-05017  BOLT
44191-24F01  SHIELD, HEAT NO.1
44192-24F00  SHIELD, HEAT NO.2
44193-24F00  SHIELD, HEAT NO.3
09139-06029  BOLT, FRONT
09160-06084  WASHER
09320-09009  CUSHION
09169-06062  SPACER
44533-24F00  COVER, SIDE RH
44543-24F00  COVER, SIDE LH
44540-24F10  PLATE, SIDE
02142-0610A !  SCREW
44560-24F01 !  BRACKET, TANK
09116-06152  BOLT
09320-08001  CUSHION
09169-06062  SPACER
44541-24F00  CUSHION, JOINT
44561-33E10  SPACER
01550-0895A !  BOLT
44574-33E01  STAY
09251-07003  PLUG
44550-24F00  BRACKET, REAR
01550-0812A !  PLUG, OIL DRAIN
01550-0616A !  BOLT
44423-24F00  HOSE, BREATHER
09352-70113-600  HOSE, DRAIN | L:600!500
09403-05310  CLIP
44534-24F00  CUSHION, FRONT
44534-24F00 !  CUSHION, FRONT
44271-24F00  SHEET, HEAT SHIELD RUBBER
09407-18402  CLAMP
09409-06322-5PK  CLIP (BLACK)
44194-24F00  SHIELD, TANK HEAT RH
44195-24F00  SHIELD, TANK HEAT LH
09404-06432  CLAMP, DRAIN HOSE
44100-24F02-CN4  TANK ASSY, FUEL
44100-24F02-CN5  TANK ASSY, FUEL
44100-24F12-CN4  TANK ASSY, FUEL | E33
44100-24F12-CN5  TANK ASSY, FUEL | E33
44100-24F02-M9T  TANK ASSY, FUEL | E28; Includes Item(s) 2 - 2
68111-32B10-Y2D  EMBLEM (SILVER) | FOR CN4
68111-32B10-17U  EMBLEM (GRAY) | FOR CN5
68111-32B10-Y7L  EMBLEM (BLACK) | FOR M9T
44201-33810  CAP SET, FUEL TANK
44200-33890  CAP SET, FUEL TANK | E33
09106-05017  BOLT
44191-24F01  SHIELD, HEAT NO.1
44192-24F00  SHIELD, HEAT NO.2
44193-24F00  SHIELD, HEAT NO.3
09139-06029  BOLT, FRONT
09160-06036  WASHER
09320-09009  CUSHION
09169-06062  SPACER
44533-24F00  COVER, SIDE RH
44543-24F00  COVER, SIDE LH
44540-24F10  PLATE, SIDE
02142-0610A !  SCREW
44560-24F01 !  BRACKET, TANK
09116-06152  BOLT
09320-08001  CUSHION
09169-06062  SPACER
44541-24F00  CUSHION, JOINT
44561-33E10  SPACER
01550-0895A !  BOLT
44574-33E01  STAY
09251-07003  PLUG
09403-05310  CLIP
44550-24F00  BRACKET, REAR
01550-0812A !  PLUG, OIL DRAIN
44423-24F00  HOSE, BREATHER
09352-70113-600  HOSE, DRAIN | L:600!500
09404-06432  CLAMP, DRAIN HOSE
44534-24F00  CUSHION, FRONT
44534-24F00 !  CUSHION, FRONT
44271-24F00  SHEET, HEAT SHIELD RUBBER
09407-18402  CLAMP
09409-06322-5PK  CLIP (BLACK)
44194-24F00  SHIELD, TANK HEAT RH
44195-24F00  SHIELD, TANK HEAT LH
11400-24876 !  GASKET SET | OPT MODEL X
11400-24876 !  GASKET SET | OPT MODEL Y/K1/K2/K3; Includes Item(s) 2 - 20
11141-24F00  GASKET, CYLINDER HEAD | NOT SHOWN
11173-24F00  GASKET, CYLINDER HEAD COVER NO.1 | NOT SHOWN
11178-33E00  GASKET, CYLINDER HEAD COVER NO.2 | NOT SHOWN
11241-15H00 !  GASKET, CYLINDER | NOT SHOWN
11318-24F01  GASKET, BREATHER COVER | NOT SHOWN
11482-24F00  GASKET, CLUTCH COVER (NA) | NOT SHOWN
11483-24F00  GASKET, MAGNETO COVER | NOT SHOWN
11485-24F00  GASKET, GEAR SHIFT COVER (NA) | NOT SHOWN
11489-24F10 !  GASKET, OIL PAN | MODEL X NOT SHOWN
11489-24F10 !  GASKET, OIL PAN | MODEL Y/K1/K2/K3 NOT SHOWN
11491-24F01 !  GASKET, STARTER CLUTCH COVER | MODEL X NOT SHOWN
11491-24F01  GASKET, STARTER CLUTCH COVER | MODEL Y/K1/K2/K3 NOT SHOWN
11492-24F00  GASKET, STARTER IDLE GEAR CAP | NOT SHOWN
12837-24A10  GASKET, TENSIONER ADJUSTER | NOT SHOWN
14181-22D01  GASKET, EXHAUST PIPE | NOT SHOWN
14181-33E00  GASKET, MUFFLER JOINT | NOT SHOWN
16491-24F00  O RING, OIL PUMP | NOT SHOWN
09161-11008  WASHER | NOT SHOWN
09280-12012  O RING (D:2.4,ID:11.8) | NOT SHOWN
09280-19008  O RING (ID:20.3,DD:2.62) | NOT SHOWN
09280-33004  O RING (D:3.1,ID:32.7) | NOT SHOWN
25211-24F10 !  FORK, GEAR SHIFT NO.1 | MODEL X/Y/K1
25211-24F10  FORK, GEAR SHIFT NO.1 | MODEL K2/K3
25231-24F20 !  FORK, GEAR SHIFT NO.3 | MODEL X/Y/K1
25231-24F20 !  FORK, GEAR SHIFT NO.3 | MODEL K2/K3
25411-24F00  SHAFT, GEAR SHIFT FORK NO.2
25411-38B01  SHAFT, GEAR SHIFT FORK NO.1
24741-24F00  RETAINER, SHIFT CAM
25310-24F00  CAM, GEAR SHIFT | Includes Item(s) 7
04221-04089  PIN, SHIFT CAM
25312-12C00  STOPPER, SHIFT CAM | MODEL X/Y/K1
25312-42F01 !  PIN, SHIFT CAM DRIVEN GEAR | MODEL K2/K3
25381-13E10  PLATE, GEAR SHIFT
09126-06011  SCREW, SHIFT CAM (6X12)
09262-25006  BEARING, SHIFT CAM (25X47X8)
09263-25018  BEARING, GEAR SHIFT CAM LH | 25X32X12
25350-12C00  STOPPER, SHIFT CAM | MODEL X
25350-24F00  ST0PPER, SHIFT CAM | MODEL Y/K1/K2/K3
25355-24F00  SPRING. STOPPER ARM
09111-06041  BOLT (6X14.3)
08211-06141  WASHER
25510-24F00  SHAFT, GEAR SHIFT
25512-13E11  PLATE, GEAR SHIFT
25671-01011 !  STOPPER, ARM | MODEL X/Y
25671-01011  STOPPER, GEAR SHIFT | MODEL K1/K2/K3
09181-14167  WASHER, GEAR SHIFT RH | 14X22X1.0

09263-14027  BEARING, GEAR SHIFT SHAFT | 14X20X12
09283-14006  SEAL, SHIFT SHAFT OIL | 14X22X6.0
09440-17009  SPRING. GEAR SHIFT PLATE
09444-20001  SPRING, SHIFT SHAFT
08331-3114A !  CIRCLIP, GEAR SHAFT
25520-24F00  ARM, GEAR SHIFT LINK | MODEL X
25520-24F10  ARM, GEAR SHIFT LINK | MODEL Y/K1/K2/K3; Includes Item(s) 27
25526-47000  COVER, DUST
25525-03F00  ROD, GEAR SHIFT LINK
25600-24F00  LEVER ASSY, GEAR SHIFT | Includes Item(s) 30 - 31
25526-47000  COVER, DUST
25652-16500  RUBBER
25617-03F10 !  SHAFT, GEAR SHIFT LEVER
09140-06020  NUT
09160-12011  WASHER (12.5X20X1.0)
01500-0625A !  BOLT, REAR
09140-06025  NUT
08331-3112A !  CIRCLIP, GEAR SHIFT LEVER
37730-24F00  BASE ASSY, GEAR SHIFT TERM
31497-45000  CLAMP, GEAR SHIFT LEAD
09209-05011  CONTACT, GEAR SHIFT
09440-04010  SPRING, GEAR SHIFT SW
07130-0510B !  BOLT, SENSOR
07120-0516B !  BOLT
57110-46E02 !  GRIP,THROTTLE
57300-33E01  LEVER ASSY, BRAKE | Includes Item(s) 3 - 4
57431-17C00  BOLT, KNOCKER
08316-1006B !  NUT
57460-14J01 !  SWITCH ASSY, STOP | Includes Item(s) 6
57465-17C00  SCREW
57211-22D02-291 !  GRIP, LH (BLACK)
57500-24F01 !  LEVER ASSY,CLUT | Includes Item(s) 9 - 10
57431-17C00  BOLT
08316-1006B !  NUT
57560-02FA0  SWITCH ASSY, CLUTCH
37200-33E31  SWITCH ASSY, HANDLE RH | Includes Item(s) 2 - 3
02112-0530B !  SCREW
02112-0550B !  SCREW
37400-24F30  SWITCH ASSY, HANDLE LH | Includes Item(s) 5 - 6
02112-0525A !  SCREW, PIVOT
02112-0545B !  SCREW
02112-0510A !  SCREW, THROTTLE
56111-24F01 !  HANDLEBAR, RH | MODEL X
56111-24F01  HANDLEBAR, RH | MODEL Y/K1/K2/K3
56151-24F01 !  HANDLEBAR, LH | MODEL X
56151-24F01  HANDLEBAR, LH | MODEL Y/K1/K2/K3
56210-24F00  HOLDER, HANDLE | Includes Item(s) 4
68281-24F00  EMBLEM
56210-24F10  HOLDER, HANDLEBAR | GSX1300RZK3 E3,E33; Includes Item(s) 4B
68281-24F30  EMBLEM | GSX1300RZK3 E3,E33
56247-24F00  CUSHION, HANDLE HOLDER
56246-24F00  CAP, BOLT
07130-10607  BOLT
56240-01D00  CUSHION
56243-01D00  SPACER
09160-10094  WASHER
08319-31107  NUT
07130-0625B !  BOLT | MODEL X
09106-06090  BOLT, CLAMP | MODEL Y/K1/K2/K3
09250-05009  CAP
56200-08830  BALANCER SET, HANDLEBAR | Includes Item(s) 15
02122-0660B !  SCREW
56500-24F20 !  MIRROR ASSY, REAR VIEW RH
56600-24F20 !  MIRROR ASSY, REAR VIEW LH
94576-24F00  CUSHION
01547-0630B !  BOLT, SEC CASE
58300-24F00  CABLE ASSY, THROTTLE NO.1 | MODEL X/Y/K1
58300-24F20  CABLE ASSY, THROTTLE NO.1 | MODEL K2/K3
58300-24F10  CABLE ASSY, THROTTLE NO.2 | MODEL X/Y/K1
58300-24F30  CABLE ASSY, THROTTLE NO.2 | MODEL K2/K3
58623-24F00  GUIDE, CABLE
09103-05017 !  BOLT | MODEL X/Y/K1
09103-05017  BOLT | MODEL K2/K3
58410-24F00  CABLE, STARTER
35100-24F01-999  HEADLAMP ASSY | Includes Item(s) 2 - 4
35175-24F00  ADAPTER ASSY
35125-24F10  SOCKET, COVER
35125-24F00  SOCKET, COVER
09471-12188  BULB (12V,55W,H7,PX26D, PHILIPS) | PURCHASE LOCALLY
09471-12151  BULB (12V,60W,HB3,P20D) | PURCHASE LOCALLY
09160-05045  WASHER (5.5X18X1.0)
09320-09039  CUSHION
03511-0516A !  SCREW
35950-14A00  REFLEX-REFLECTOR ASSY | MODEL X/Y/K1/K2
35950-14A11 !  REFLEX-REFLECTOR ASSY, FR | MODEL K3
35956-02F00  BRACKET, RH
35957-02F00  BRACKET, LH
08310-0005A !  NUT | MODEL X/Y/K1/K2
08316-1005A !  NUT | MODEL K3
32101-24F00  STATOR ASSY | MODEL X/Y/K1
32101-24F10  STATOR ASSY | MODEL K2/K3
32102-24F00  ROTOR ASSY | MODEL X/Y/K1
32102-24F10  ROTOR ASSY | MODEL K2/K3
32371-24F00  CLAMP, MAGNETO
07130-0512B !  BOLT, PULSER/CLAMP
09103-12028  BOLT, MAGNETO ROTOR | 12X30
09160-12036  WASHER, MAGNETO ROTOR | 12X30X3
07130-0635B !  BOLT, MAGNETO STATOR
09420-04008  KEY
14100-24F40  PIPE, EXHAUST
14181-22D01  GASKET
07130-0825B !  BOLT
14181-33E00  GASKET
09159-08116  NUT
09160-08059  WASHER (8.5X18X1.6)
09280-08012  O RING (D:1.9,ID:7.8)
14771-24F01 !  CONNECTOR
01550-0840A !  BOLT
14459-24F30  CLAMP, CONNECTOR MUFFLER RH
14230-24F40  PIPE, JOINT RH
14240-24F30  PIPE, JOINT LH
09118-08152-A05 !  BOLT
09320-12067  CUSHION
09180-08152  SPACER
14310-24F00-H01  BODY, MUFFLER RH
14340-24F00-H01  BODY, MUFFLER LH
09103-08358  BOLT
09160-08142  WASHER (8.5X28X1.5)
09320-12049  CUSHION
09180-08156  SPACER
09159-08034  NUT
14100-24F10  PIPE, EXHAUST
14181-22D01  GASKET
07130-0825B !  BOLT
14181-33E00  GASKET
09159-08116 !  NUT | MODEL X
09159-08116  NUT | MODEL Y/K1
09160-08120 !  WASHER | MODEL X
09160-08059  WASHER (8.5X18X1.6) | MODEL Y/K1
09280-08012  O RING (D:1.9,ID:7.8)
14771-24F01 !  CONNECTOR
01550-0840A !  BOLT
14240-24F00  PIPE, JOINT LH
09118-08152-A05 !  BOLT
09320-12067  CUSHION
09180-08152  SPACER
14310-24F00-H01  BODY, MUFFLER RH
14340-24F00-H01  BODY, MUFFLER LH
01550-08457  BOLT | MODEL X
09103-08358  BOLT | MODEL Y/K1
09160-08136  WASHER (8.5X28X1.6) | MODEL X
09160-08142  WASHER (8.5X28X1.5) | MODEL Y/K1
09320-12049  CUSHION
09180-08156  SPACER
09159-08034  NUT
16600-24F10 !  COOLER ASSY, OIL | MODEL X/Y/K1
16600-24F10 !  COOLER ASSY, OIL | MODEL K2/K3
09116-06115  BOLT (6X20) | MODEL X/Y/K1
09116-06167  BOLT (6X20) | MODEL K2/K3
09180-06310  SPACER
09320-10501  CUSHION
16640-24F00  BRACKET, OIL COOLER
01547-0612B !  BOLT
16460-24F01  HOSE, OIL COOLER RH
16470-24F02  HOSE, OIL COOLER LH
09280-12012  O RING (D:2.4,ID:11.8)
07130-0616A !  BOLT, SENSOR | MODEL X
09106-06096  BOLT, RH (6X16) | MODEL Y/K1/K2/K3
07130-0620B !  BOLT | MODEL X
09106-06097  BOLT, LH (6X20) | MODEL Y/K1/K2/K3
16650-24F01 !  GUARD, OIL COOLER | MODEL X/Y/K1
16650-24F01  GUARD, OIL COOLER | MODEL K2/K3; Includes Item(s) 13 - 14
16654-27E00  PROTECTOR | MODEL X/Y/K1
17765-09F00  PROTECTOR, CTR | MODEL K2/K3
09352-30503-600  HOSE (3X5X600) | L:600!40
11511-24F10 !  PAN, OIL
11489-24F10 !  GASKET, OIL PAN
01547-0630B !  BOLT, SEC CASE
01547-0640B !  BOLT
09168-06023  GASKET (5.8X13X1.2)
09247-14036  PLUG, OIL DRAIN
09168-14004 !  GASKET
16520-24F01 !  STRAINER, ENGINE OIL
01550-0620A !  BOLT, SHIFT LEVER
09280-19008  O RING (D:2.62,ID:20.3)
16440-24F00  VALVE ASSY, OIL RELIEF
16400-24F01  PUMP ASSY, ENGINE OIL
16491-24F00  O RING
01547-0630B !  BOLT, SEC CASE
16321-33E10  GEAR, OIL PUMP DRIVE (NT:34)
16331-33E00  GEAR, OIL PUMP DRIVEN (NT:37)
09181-12158  WASHER
09261-05006  PIN
08331-3112A !  CIRCLIP, GEAR SHIFT LEVER
99000-25110  SUZUKI PBC GREASE | 20G
99000-32020 !  THREAD LOCK, SUPER (1333B) | 50G
99000-32030 !  THREAD LOCK, SUPER (1303B) | 50G
99000-32050  THREAD LOCK SUPER (1342) | 50G
99000-32100  THREAD LOCK SUPER (1305) | 50G
99000-32130  THREAD LOCK SUPER (1360) | 50G
99000-32040  THREAD LOCK CEMENT | 200G
99104-31140 !  LIQUID GASKET 1 | 100G
99104-31140 !  LIQUID GASKET 1 | 100G
99000-25030  SUZUKI SUPER GREASE | 150G
99000-25140  SUZUKI MOLY PASTE | 50G
15100-24FB0 !  PUMP ASSY, FUEL | MODEL K1
15100-24FB0  PUMP ASSY, FUEL | MODEL K2/K3; Includes Item(s) 2 - 15
15909-24FV0 !  FILTER ASSY, FU | MODEL K1
15410-24FB0  FILTER ASSY, FUEL | MODEL K2/K3
15420-35F01  STRAINER, FUEL PUMP | MODEL K1
15420-24FB0  STRAINER, FUEL PUMP | MODEL K2/K3
15111-35F00  CUSHION, FUEL PUMP
15112-35F00  HOLDER, FUEL PUMP | MODEL K1
15112-42F00  HOLDER, FUEL PUMP | MODEL K2/K3
15114-35F00  BUSH, FUEL PUMP
15113-35F00  O RING
15115-35F00  NUT
15116-35F10 !  SCREW | MODEL K1
15116-35F10  SCREW | MODEL K2/K3
34810-24FA0  GAUGE ASSY, FUEL LEVEL
15171-35F00  WASHER
15172-35F00  SPRING WASHER
15173-35F00  NUT
15181-24FA0  BRACKET, FUEL GAUGE | MODEL K1
15181-24FB0  BRACKET, FUEL GAUGE | MODEL K2/K3
15116-35F10 !  SCREW | MODEL K1
15201-35F00  O RING
07120-0612B !  PLUG
15810-24FA0  HOSE, FUEL
15100-24F30 !  PUMP ASSY, FUEL | MODEL X
15100-24F30  PUMP ASSY, FUEL | MODEL Y; Includes Item(s) 2 - 27
15130-24F10  INSULATOR
15142-24F00  O RING
15141-24F00  INSULATOR
15143-24F00  PLATE, STAY
15144-24F00  PACKING
15145-24F00  COLLAR | MODEL X
15145-24F30  COLLAR | MODEL Y
15146-24F00  O RING
15151-24F00  SPRING | MODEL X
15151-24F30  SPRING | MODEL Y
15410-24F00  STRAINER, FUEL | MODEL X
15152-24F30  STRAINER, FUEL | MODEL Y
15155-24F00  COLLAR
15180-24F00  PUMP ASSY, FUEL
15147-24F00  HARNESS (+)
15148-24F00  HARNESS (-)
15154-24F00  HOUSING, CONNECTOR
15153-24F00  SCREW
15610-24F00  REGULATOR ASSY, PRESSURE
15156-24F00  O RING
15157-24F00  O RING
15158-24F00  JOINT
15159-24F00  O RING
15161-24F00  SCREW
15162-24F00  PACKING
15163-24F00  BOLT
15164-24F00  SCREW
15165-24F00  SCREEN, FUEL STRAINER
15721-24F00  O RING
15170-24F00  PIPE SET
13611-24F10  BOLT
15211-24F00  PLATE, FUEL PUMP STAY LH
15212-24F00  PLATE, FUEL PUMP STAY RH
15801-24F00  HOSE, FUEL RETURN | MODEL X
15801-24F10  HOSE, FUEL RETURN | MODEL Y
09440-17020-XC0 !  SPRING
09401-13417  CLIP, PUMP SIDE | MODEL X
09401-14404  CLIP, PUMP SIDE | MODEL Y
09401-11415 !  CLIP | MODEL X
09401-12405  CLIP, TANK SIDE | MODEL Y
15310-24F00  COVER, FUEL PUMP
17710-24F01 !  RADIATOR ASSY, WATER | MODEL X/Y
17710-24F01  RADIATOR ASSY, WATER | MODEL K1
17710-24F10  RADIATOR ASSY, WATER | MODEL K2/K3
17730-08J00 !  CAP, RADIATOR
09116-06147  BOLT (6X25) | MODEL X/Y/K1
09118-06097  BOLT (6X25) | MODEL K2/K3
09180-06290  SPACER
09320-10042  CUSHION
17750-24F00  BRACKET, RADIATOR LOWER
01547-0612B !  BOLT
17800-24F01 !  FAN ASSY, RADIATOR | MODEL X/Y
17800-24F01  FAN ASSY, RADIATOR | MODEL K1/K2/K3
01550-0610A !  BOLT
09148-06015  NUT
09407-18402  CLAMP, RADIATOR FAN LEAD
17851-24F01 !  HOSE, RADIATOR INLET | MODEL X/Y/K1
17851-24F01  HOSE, RADIATOR INLET | MODEL K2/K3
17852-24F00  HOSE, RADIATOR OUTLET
17853-24F00  HOSE, CYLINDER INLET
09402-38511  CLAMP
09401-12414 !  CLIP
17859-24F00  CLAMP, RADIATOR INLET HOSE
01550-0610A !  BOLT
17854-24F00  HOSE, WATER BYPASS NO.1
17855-24F00  HOSE, WATER BYPASS NO.2
09362-09011  UNION, BYPASS
17661-24F00  COVER, THERMOSTAT
17670-50F00  THERMOSTAT, WATER
01547-0620B !  BOLT
09404-06432 !  CLAMP (L:65)
17861-33E20 !  CONNECTOR, CYLINDER INLET | MODEL X/Y/K1
17861-33E20 !  CONNECTOR, CYLINDER INLET | MODEL K2/K3
17863-33E00  O RING
01550-0620A !  BOLT, SHIFT LEVER
51827-01A00 !  CUSHION
53145-48B00  CUSHION, RESERVOIR TANK LH
17680-33E00  SWITCH, RADIATOR FAN | Includes Item(s) 19A
17689-50F00  O RING
17910-24F00  TANK ASSY, RESERVOIR | Includes Item(s) 21
17932-12C00  CAP
09136-06022  SCREW (6X20)
17981-21810  HOSE, RESERVOIR TANK INLET
09401-08411  CLIP
17982-38810  HOSE, OVER FLOW
09407-18402  CLAMP, RESERVOIR TANK HOSE
09407-18402  CLAMP, RADIATOR OUTLET HOSE
69100-05CG0-999  CALIPER ASSY, REAR | Includes Item(s) 1 - 9
69100-05851  PISTON SET
69101-05840 !  SEAL SET, PISTON
59145-05C50  BOLT
59143-16700  SPRING
69141-46E01  PIN
69142-46E01  CLIP
59151-16701  COVER
59121-18410  BLEEDER
55156-66310  CAP
69102-05860  PAD & SHIM SET
09103-08359  BOLT
69100-05CG0-999 !  CALIPER ASSY, REAR | Includes Item(s) 1 - 12
69100-05851 !  PISTON SET
69101-05840 !  SEAL SET, PISTON
69101-05820  PAD SET
59145-05C50  BOLT
59143-16700  SPRING
69141-46E01  PIN
69142-46E01  CLIP
59151-16701  COVER
59121-18410  BLEEDER
55156-66310  CAP
59371-20C00  SHIM, INNER
59381-20C00  SHIM, OUTER
01550-0830A !  BOLT, EPS | MODEL X/Y
09103-08359  BOLT | MODEL K1/K2
62600-24810  LEVER SET, REAR CUSHION | Includes Item(s) 2 - 4
09263-20073  BEARING, FRONT (20X27X30)
09263-20071  BEARING, CENTER (20X27X23.5)
09263-17034  BEARING, REAR (17X24X26)
62684-12C00  SPACER, FRONT (12X20X32)
08211-12301  WASHER
62658-19F00  BOLT, FRONT (12X78)
08319-3112A !  NUT
62626-24F00  SPACER, CENTER (12X20X94)
62621-33D00  BOLT, CENTER (12X124)
08319-3112A !  NUT
62684-40A10  SPACER, REAR (10X17X30)
62641-24F00  ROD, REAR CUSHION
62626-24F00  SPACER, ROD (12X20X94)
62621-33D00  BOLT, ROD (12X124)
08319-3112A !  NUT
62100-24F01 !  ABSORBER ASSY, REAR SHOCK | MODEL X/Y
62100-24F20  ABSORBER ASSY, REAR SHOCK | MODEL K1/K2 E3
62100-24F01  ABSORBER ASSY, REAR SHOCK | MODEL K1/K2 E28
62100-24F40  ABSORBER ASSY, REAR SHOCK | MODEL K3 E3
62100-24F30  ABSORBER ASSY, REAR SHOCK | MODEL K3 E28
09103-10033  BOLT, UPPER (10X70)
09103-10027  BOLT, LOWER (10X58)
08319-31107  NUT
63111-24F21 !  FENDER, REAR | MODEL X/Y/K1/K2
63111-24F21  FENDER, REAR | MODEL K3
09113-06001  BOLT, FRONT
09113-06001  BOLT, REAR
08316-1006B !  NUT
63411-24F00  MUDGUARD, REAR
09409-07333  CLIP
63421-24F00  MUDGUARD, REAR UPPER
09800-21039  TOOL ASSY
09462-00093  BAND, TOOL
69600-33C00  CYLINDER ASSY, REAR MASTER | Includes Item(s) 2 - 9
69600-04820  PISTON / CAP SET
69691-00A00  BOOT
69692-27A30  YOKE
69670-48B00  ROD, PUSH
69693-05A00  NUT
69672-05A00  CONNECTOR
69686-34200  O RING
02112-7412A !  SCREW
09139-06028  BOLT (6X20)
69740-01D02  TANK ASSY, REAR RESERVOIR | Includes Item(s) 12 - 14
59667-04700  DIAPHRAGM
59669-05D00  CAP
69689-04A00  SCREW
01550-0612A !  BOLT, REAR COMB BRACKET
69731-24F00  HOSE, RESERVOIR TANK
09401-13417  CLAMP
69480-24F02 !  HOSE COMP,REAR
09360-10061 !  BOLT (10X1.00X22)
09360-10062 !  BOLT, UPPER
09161-10009  WASHER (10X15X1.5)
09200-06068 !  PIN
08322-0106B !  WASHER
04111-2015A !  PIN, COTTER
69750-24F00  BRACKET, RESERVOIR TANK
01550-0612A !  BOLT, REAR COMB BRACKET
69600-33C00  CYLINDER ASSY, REAR MASTER | Includes Item(s) 2 - 9
69600-04820  PISTON / CAP SET
69691-00A00  BOOT
69692-27A30  YOKE
69670-48B00  ROD, PUSH
69693-05A00  NUT
69672-05A00  CONNECTOR
69686-34200  O RING
02112-7412A !  SCREW
09139-06028  BOLT (6X20)
69740-01D02  TANK ASSY, REAR RESERVOIR | Includes Item(s) 12 - 14
59667-04700  DIAPHRAGM
59669-05D00  CAP
69689-04A00  SCREW
01550-0612A !  BOLT, REAR COMB BRACKET
69731-24F00  HOSE, RESERVOIR TANK
09401-13417  CLAMP
69480-24F02 !  HOSE COMP,REAR | MODEL X
69480-24F02 !  HOSE COMP,REAR | MODEL Y/K1/K2
09360-10061 !  BOLT (10X1.00X22)
09161-10009  WASHER (10X15X1.5)
09200-06068 !  PIN
08322-0106B !  WASHER
04111-2015A !  PIN, COTTER
69750-24F00  BRACKET, RESERVOIR TANK
01550-0612A !  BOLT, REAR COMB BRACKET
61000-24F30  SWINGING ARM ASSY, REAR | GSX1300RK3
61000-24F20  SWINGING ARM ASSY, REAR | GSX1300RZK3; Includes Item(s) 2 - 4
61281-33E20 !  SPACER, CENTER
09263-30040  BEARING, PIVOT (30X40X25)
09263-20071  BEARING, ROD (20X27X23.5)
61124-33E00  PLATE, BRACKET
02142-0616A !  SCREW | GSX1300RK3
09125-06073  SCREW | GSX1300RZK3
61251-17E20 !  SPACER, BEARING
08211-25481  WASHER
61262-17E10  SEAL, DUST
61211-16G00  SHAFT, PIVOT
61214-40C31  NUT, PIVOT SHAFT
09160-25070  WASHER
09159-25003 !  NUT
61273-24F00  BUFFER, CHAIN TOUCH DEFENSE
09116-06152  BOLT (6X20)
09180-06306  SPACER (6.5X9X5)
61311-33E01  CASE, CHAIN
09139-06083  SCREW (6X16)
61446-33E10  ADJUSTER, CHAIN RH
61445-33E00  ADJUSTER, CHAIN LH
09100-08287  BOLT (8X50)
08316-1008B !  NUT
64310-24F00  TORQUELINK, REAR
09111-08085  BOLT, FRONT (8X35.5)
08319-31087  NUT
09103-10019  BOLT, REAR (10X37)
08319-31107  NUT
61000-24F00  SWINGING ARM ASSY, REAR | GSX1300RX/Y/K1/K2
61000-24F10  SWINGING ARM ASSY, REAR | GSX1300RZK2; Includes Item(s) 2 - 4
61281-33E20 !  SPACER, CENTER
09263-30040  BEARING, PIVOT (30X40X25)
09263-20071  BEARING, ROD (20X27X23.5)
61124-33E00  PLATE, BRACKET
02142-0616A !  SCREW
61251-17E20 !  SPACER, BEARING
08211-25481  WASHER
61262-17E10  SEAL, DUST
61211-33E00  SHAFT, PIVOT
61214-40C31  NUT, PIVOT SHAFT
09160-25070  WASHER
09159-25003 !  NUT
61273-24F00  BUFFER, CHAIN TOUCH DEFENSE
09116-06152  BOLT (6X20)
09180-06306  SPACER (6.5X9X5)
61311-33E01  CASE, CHAIN
09139-06083  SCREW (6X16)
61446-33E10  ADJUSTER, CHAIN RH
61445-33E00  ADJUSTER, CHAIN LH
09100-08287  BOLT (8X50)
08316-1008B !  NUT
64310-24F00  TORQUELINK, REAR
09111-08085  BOLT, FRONT (8X35.5)
08319-31087  NUT
09103-10019  BOLT, REAR (10X37)
08319-31107  NUT
64111-33E11-35W !  WHEEL,RR,17M/CX | GSX1300RX/Y/K1/K2
64111-33E11-019 !  WHEEL, REAR (17XMT6.00) (BLACK) | GSX1300RZK2/K3
64731-33E10  SPACER, HUB BEARING
09262-32008  BEARING (32X58X13)
09285-38001  SEAL, RH (38X58X7)
69211-21E00  DISC, REAR BRAKE
09106-08148 !  BOLT, DISC | MODEL X
09106-08148  BOLT (8X33) | MODEL Y/K1/K2/K3
69721-24F00  BRACKET, REAR CALIPER
64711-33E10  AXLE, REAR
04111-4040A !  COTTER PIN
09141-25001  NUT
64741-33E00  SPACER, AXLE RH
64751-24F00  SPACER, AXLE LH
64611-33E02  DRUM, REAR SPROCKET
64733-33E00  RETAINER, SPROCKET DRUM
09262-32022 !  BEARING (32X65X17)
09285-39001  SEAL (39X65X7)
64651-31001  ABSORBER, HUB SHOCK
64511-24F01  SPROCKET, REAR (NT:40-530)
09119-10059  BOLT (10X38)
08322-01107  WASHER
08319-31107  NUT
65110-24F10 !  TIRE, REAR,190/50 ZR17 (73W) (BRIDGESTONE) | MODEL X
65110-24F10  TIRE, REAR,190/50 ZR17 (73W) (BRIDGESTONE) | MODEL Y/K1/K2/K3
43130-24A00  VALVE ASSY, WHEEL RIM (TR412)
55411-00A00 !  BALANCER (10G)
55412-17G00 !  BALANCER, WHEEL, NO.2
45100-24F10-W05  SEAT ASSY (BLACK) | Includes Item(s) 2 - 10
45149-45330  CUSHION
09321-10011  CUSHION
45117-47D00  CUSHION
45116-24F10  BRACKET, SEAT FRONT RH
09160-06066  WASHER
45149-24F01  CUSHION (10X20X10)
09180-06310  SPACER (6.5X10X10)
45117-24F00  WASHER, SEAT
08316-1006B !  NUT
45300-24F10-W05 !  SEAT ASSY, PILLION (BLACK) | Includes Item(s) 12
45213-31300  CUSHION
45191-24F00  BOLT, SEAT FRONT (6X40)
45220-47H00 !  BRACKET, SEAT SUPPORT
02122-0630B !  SCREW
95700-14810  LOCK ASSY, SEAT
45289-11F00  PLATE, SEAT LOCK
45280-24F00  CABLE, SEAT LOCK
45288-14F00  GUIDE, CABLE
45550-24F10-1LF !  BOX, SEAT TAIL (BLUE) | FOR CN5
45550-24F10 !  BOX COMP,SEAT T | FOR FH5
45550-24F00-YC6  BOX, SEAT TAIL (RED) | FOR FH6; Includes Item(s) 21
45213-31300  CUSHION
47190-24F01 !  WASHER
46211-24F01-35W  HANDLE, PILLION RIDER (GRAY)
09103-08373  BOLT
47190-24F11 !  WASHER, PILLION RIDER HDL FR
46217-24F00  CUSHION, PILLION RIDER HDL
46212-24F11  HOOK, HANDLE
09250-05009  CAP
94401-24F30-YZX  COWLING ASSY, BODY | GSX1300RK2
94401-24F30-FH9  COWLING ASSY, BODY | GSX1300RK2
94401-24F20-HE6  COWLING ASSY, BODY | GSX1300RK2
94401-24F40-019  COWLING ASSY, BODY (BLACK) | GSX1300RZK2; Includes Item(s) 2 - 2A
68281-24F20-HT6  TAPE, FRONT | GSX1300RK2 FOR YZX
68281-24F20-HT7  TAPE, FRONT | GSX1300RK2 FOR FH9
68281-24F10-HT8  TAPE, FRONT | GSX1300RK2 FOR HE6
68641-24F00-JB5  EMBLEM | GSX1300RZK2 FOR 019
94611-24F00  WINDSCREEN
09139-05025  SCREW
08322-0105A !  WASHER, FRONT
09159-05019  NUT
94641-24F00  PANEL, UPPER RH
94651-24F00  PANEL, UPPER LH
94419-24F00  COVER, BODY COWL
94401-24F60-CN5  COWLING ASSY, BODY | GSX1300RK3
94401-24F60-KT7  COWLING ASSY, BODY | GSX1300RK3
94401-24F70-LA1  COWLING ASSY, BODY | GSX1300RK3
94401-24F40-019  COWLING ASSY, BODY (BLACK) | GSX1300RZK3 E28
94401-24F70-YAV  COWLING ASSY, BODY (ORANGE) | GSX1300RZK3 E3,E33; Includes Item(s) 2 - 3
68281-24F10-CN5  EMBLEM | GSX1300RK3 FOR CN5
68281-24F10-KT7  EMBLEM | GSX1300RK3 FOR KT7
68281-24F20-GW5  EMBLEM | GSX1300RK3 FOR LA1
68281-24F20-MZ6  EMBLEM | GSX1300RZK3 E3,E33 FOR YAV
68641-24F00-JB5  EMBLEM | GSX1300RZK3 E28 FOR 019
94611-24F00  WINDSCREEN
09139-05025  SCREW
08322-0105A !  WASHER, FRONT
09159-05019  NUT
94641-24F00  PANEL, UPPER RH
94651-24F00  PANEL, UPPER LH
94419-24F00  COVER, BODY COWL
45100-24F10-W05 !  SEAT ASSY (BLACK) | MODEL X
45100-24F10-W05 !  SEAT ASSY (BLACK) | MODEL Y; Includes Item(s) 2 - 11
45149-45330  CUSHION
09321-10011  CUSHION
45117-47D00  CUSHION
45115-24F00  BRACKET, SEAT FRONT RH
45116-24F00  BRACKET, SEAT FRONT LH
09160-06066  WASHER
45149-24F01 !  CUSHION (10X20X10)
09180-06310  SPACER (6.5X10X10)
09160-06066  WASHER | MODEL X
45117-24F00  WASHER, SEAT | MODEL Y
08316-1006B !  NUT
45300-24F10-W05 !  SEAT ASSY, PILLION (BLACK) | Includes Item(s) 13
45213-31300  CUSHION
45191-24F00  BOLT, SEAT FRONT (6X40)
45220-47H00 !  BRACKET, SEAT SUPPORT
02122-0630B !  SCREW
95700-14810  LOCK ASSY, SEAT
45289-11F00  PLATE, SEAT LOCK
45280-24F00  CABLE, SEAT LOCK
45288-14F00  GUIDE, CABLE
45550-24F00-Y7L  BOX, SEAT TAIL (BLACK) | MODEL X FOR M9T
45550-24F00-Y9K  BOX, SEAT TAIL (BROWN) | MODEL X FOR M9S
45550-24F00-YC6  BOX, SEAT TAIL (RED) | MODEL Y E3 FOR CN4
45550-24F10-1LF !  BOX, SEAT TAIL (BLUE) | MODEL Y E3 FOR CN5
45550-24F00-Y7L  BOX, SEAT TAIL (BLACK) | MODEL Y E28 FOR M9T
45550-24F10-1LF !  BOX, SEAT TAIL (BLUE) | MODEL Y E28 FOR CN5; Includes Item(s) 22
45213-31300  CUSHION
46211-24F01-35W !  HANDLE, PILLION RIDER (GRAY)
01550-0830A !  BOLT, EPS
46212-24F11 !  HOOK, HANDLE | MODEL X
46212-24F11  HOOK, HANDLE | MODEL Y
09250-05009  CAP
34120-24F12 !  SPDOM & TACH AS | MODEL X
34120-24F12 !  SPDOM & TACH AS | MODEL Y
34120-24F41 !  SPDOM & TACH AS | MODEL K1
34120-24F70  SPDOM & TACH ASSY (MILE/KILO) | MODEL K2/K3
34120-24F00  SPDOM & TACH ASSY (KILO) | MODEL X E28
34120-24F02 !  SPEEDO/TACH ASS | MODEL Y E28
34120-24F30  SPDOM & TACH ASSY (KILO) | MODEL K1 E28
34120-24F60  SPDOM & TACH ASSY (KILO) | MODEL K2/K3 E28
34150-24F00  VISOR ASSY
34123-24F00  ATTACHMENT, SWITCH
34124-33E00  SWITCH, GUM
34124-24F00  SWITCH, LEVER
09132-03005  SCREW, FAN HEAD (3X10)
34130-24F01 !  CASE ASSY | MODEL X
34130-24F01  CASE ASSY | MODEL Y/K1/K2/K3
03541-0416A !  SCREW
34955-13E00  CUSHION, METER
34187-24F00  WASHER
09116-06147  BOLT, METER (6X25)
34981-42E01 !  ROTOR,SPEED | MODEL X/Y
34981-38G01 !  ROTOR, SPEED | MODEL K1/K2/K3
34990-35F00 !  SENSOR, SPEED | MODEL X/Y
34990-35F00  SENSOR, SPEED | MODEL K1/K2/K3
07120-0512B !  BOLT, HEADLAMP ADJUST
09106-08144  BOLT, SPEED ROTOR (8X25) | MODEL X/Y
07130-0825B !  BOLT | MODEL K1/K2/K3
42310-24F00  STAND, PROP
09111-10058  BOLT, PROP STAND | MODEL X
09111-10059  BOLT, PROP STAND | MODEL Y/K1/K2/K3
08319-3110A !  NUT | MODEL X
09159-10103  NUT | MODEL Y/K1/K2/K3
09443-14066  SPRING, INNER | MODEL X
09443-14068  SPRING, INNER | MODEL Y/K1/K2/K3
09443-19012  SPRING, OUTER | MODEL X
09443-19015  SPRING, OUTER | MODEL Y/K1/K2/K3
42330-24F01 !  BRACKET, PROP STAND
01550-1235A !  BOLT | MODEL X
09100-12077  BOLT | MODEL Y/K1/K2/K3
43111-24F01 !  PEDAL, BRAKE
09160-18022  WASHER
43561-24F00  HOOK, RETURN SPRING
08331-3118A !  CLIP
09443-13030-XC0 !  SPRING | MODEL X
09443-13032  SPRING, RETURN | MODEL Y/K1/K2/K3
42100-24821 !  NO DESCRIPTION AVAILABLE | OPT; Includes Item(s) 14 - 23
42254-24F00  BOLT | OPT
42253-24F00  SPACER | OPT
42251-24F00  HOOK, SPRING | OPT
09443-14067  SPRING, INNER | OPT
09443-22018  SPRING, OUTER | OPT
94590-24F00  BRACKET, UNDER COWL | OPT
42252-24F00  BOLT, STOPPER | OPT
08319-3110A !  NUT | OPT
43576-48B10  BOLT, BANK SENSOR | OPT
09321-10017  CUSHION | OPT
12600-24F00  LIMITER ASSY, STARTER IDLE GEAR
12615-24F00  PIN
12612-24F00  GEAR, STARTER IDLE NO.2 (NT:16/14)
12151-05200  PIN
09164-14008  WASHER
12600-24850  CLUTCH SET, STARTER
09263-28031  BEARING
08211-10285  WASHER
08211-20403  WASHER
09103-10189  BOLT (10X23)
12611-24F01 !  GEAR, STARTER IDLE NO.1 | MODEL X/Y,NT:14/70
12611-24F01  GEAR, STARTER IDLE NO.1 | MODEL K1/K2,NT:14/70
12151-09204  PIN
09263-12023  BEARING
08211-12241  WASHER
09164-12021  WASHER
12612-24F00  GEAR, STARTER IDLE NO.2 (NT:16/14)
12151-05200  PIN
09164-14008  WASHER
12600-24850 !  CLUTCH SET, STARTER
09263-28031  BEARING
08211-10305  WASHER
08211-20403  WASHER
09103-10189  BOLT (10X23)
31100-24F01  MOTOR ASSY, STARTING | MODEL X/Y/K1/K2
31100-24F10  MOTOR ASSY, STARTING | MODEL K3; Includes Item(s) 2 - 13
31132-45C00  HOLDER SET, BRUSH
31143-38300  O RING
31150-24F00  HOUSING | MODEL X/Y
31150-15H20 !  HOUSING ASSY, STARTER | MODEL K1/K2/K3
31171-24F00  FRAME, STARTER END
31172-38300  BUSHING
31173-88C00  BUSHING
31264-44110  O RING
31281-24F00  BOLT
09280-24003  O RING (D:3.1,ID:24.5)
08310-00067  NUT
31170-43400 !  SHIM SET
31361-38300  SHIM
09103-06212 !  BOLT (6X25)
08361-3506A !  NUT
35710-24F30  LAMP ASSY, REAR COMBINATION | Includes Item(s) 2 - 12
35712-24F30  LENS
35912-24F00  LENS, LICENSE
35713-24F00  GASKET
35716-48B21  PLATE NO.1
35736-48B21  PLATE NO.2
35765-48B21 !  CUSHION | MODEL X/Y
35765-48B21  CUSHION | MODEL K1/K2/K3
35718-24F00  SOCKET & CORD
03211-0412A !  SCREW
03211-04207  SCREW
09471-12128 !  BULB (12V,21/5W)
09471-12081  BULB (12V,5W)
03541-0516A !  SCREW
35726-24F00  BRACKET, REAR COMB
03541-0516A !  SCREW
03541-0525B !  SCREW
35927-24F00  BRACKET, LICENSE PLATE
09160-06088  WASHER (6.5X20X1.60)
02142-0620A !  SCREW | MODEL X/Y
02142-0616A !  SCREW | MODEL K1/K2/K3
08316-1006B !  NUT
09321-06026  CUSHION
35970-14A20  REFLECTOR ASSY, REAR
35975-24F01 !  BRACKET, REAR RH
35976-24F01 !  BRACKET, REAR LH
02112-0616A !  SCREW | MODEL X/Y
02112-0612A !  SCREW | MODEL K1/K2/K3
08316-1006B !  NUT
13401-24FA0  THROTTLE BODY ASSY, LH | E3,E28
13401-24FB0  THROTTLE BODY ASSY, LH | E33
13402-24FA0  THROTTLE BODY ASSY, ML | E3,E28
13402-24FB0  THROTTLE BODY ASSY, ML | E33
13403-24FA0  THROTTLE BODY ASSY, MR | E3,E28
13403-24FB0  THROTTLE BODY ASSY, MR | E33
13404-24FA0  THROTTLE BODY ASSY, RH | E3,E28
13404-24FB0  THROTTLE BODY ASSY, RH | E33
15710-24F00  INJECTOR ASSY
15721-24F00  O RING
15722-24F00  RING, CUSHION
13672-24F00  RING, SEAL
13601-35F00  SCREW
13471-35F00  JOINT, NO.1
13471-35F10  JOINT, NO.2,3
13471-35F20  JOINT, NO.4
13474-24F00  JOINT
15721-24F00  O RING
13611-24F00  BOLT
13607-24F00  NUT
13423-35F00  SCREW, STOP
13543-24F00  SPRING
13268-03F50  SPRING
13543-24F20  SPRING
13602-24F10  SCREW, STOP
13543-24F30  SPRING
13267-35F00  SCREW, STOP
13273-24F00  WASHER
13271-24F00  SPRING
13580-24F00  SENSOR ASSY, THROTTLE
13582-24F00  COLLAR
13575-24F00  O RING
13613-24F00  SCREW
13572-03F00 !  WASHER
13432-24F10  CLAMP | E3,E28
13619-24F10  CLAMP | E33
13508-24F00  CAP, RUBBER
13697-24F00  HOSE, RUBBER (L:35)
13697-24F20  HOSE, RUBBER (L:100)
13697-24F30  HOSE, RUBBER (L:200)
13697-24FA0  HOSE, RUBBER (L:230+20)
13471-24F30  JOINT
13432-24FA0  CLAMP
13565-24F00  PLATE, STAY
13601-24F00  SCREW
13698-24F00  HOSE, RUBBER (L:80+25) | E33
13698-24F10  HOSE, RUBBER (L:35) | E33
13698-24F20  HOSE, RUBBER (L:30+30) | E33
13698-24F30  HOSE, RUBBER (L:440+30) | E33
13693-24F00  CLIP | E33
13685-36E50  JOINT | E33
13473-35F01  JOINT
13401-24FJ0  THROTTLE BODY ASSY, LH | E3,E28
13401-24FH0  THROTTLE BODY ASSY, LH | E33
13402-24FJ0  THROTTLE BODY ASSY, ML | E3,E28
13402-24FH0  THROTTLE BODY ASSY, ML | E33
13403-24FJ0  THROTTLE BODY ASSY, MR | E3,E28
13403-24FH0  THROTTLE BODY ASSY, MR | E33
13404-24FJ0  THROTTLE BODY ASSY, RH | E3,E28
13404-24FH0  THROTTLE BODY ASSY, RH | E33
15710-24F00  INJECTOR ASSY
15721-24F00  O RING
15722-24F00  RING, CUSHION
13672-24F00  RING, SEAL
13601-35F00  SCREW
13471-35F00  JOINT, NO.1
13471-35F10  JOINT, NO.2,3
13471-35F20  JOINT, NO.4
13474-24F00  JOINT
15721-24F00  O RING
13611-24F00  BOLT
13607-24F00  NUT
13423-35F00  SCREW, STOP
13543-24F00  SPRING
13268-03F50  SPRING
13543-24F20  SPRING
13602-24F10  SCREW, STOP
13543-24F30  SPRING
13267-35F00  SCREW, STOP
13273-24F00  WASHER
13271-24F00  SPRING
13580-40F21 !  SENSOR ASSY, THROTTLE NO.1
13575-24F00  O RING
13605-40F00  SCREW
13432-24F10  CLAMP | E3,E28
13619-24F10  CLAMP | E33
13697-24F00  HOSE, RUBBER (L:35)
13697-24F20  HOSE, RUBBER (L:100)
13697-24F30  HOSE, RUBBER (L:200)
13697-24FA0  HOSE, RUBBER (L:230+20)
13471-24F30  JOINT
13432-24FA0  CLAMP
13565-24F00  PLATE, STAY
13601-24F00  SCREW
13698-24F00  HOSE, RUBBER (L:80+25) | E33
13698-24F10  HOSE, RUBBER (L:35) | E33
13698-24F20  HOSE, RUBBER (L:30+30) | E33
13698-24F30  HOSE, RUBBER (L:440+30) | E33
13693-24F00  CLIP | E33
13685-36E50  JOINT | E33
13473-35F01  JOINT
13401-24F00  THROTTLE BODY ASSY, LH | E3,E28
13401-24F10  THROTTLE BODY ASSY, LH | E33
13402-24F00  THROTTLE BODY ASSY, ML | E3,E28
13402-24F10  THROTTLE BODY ASSY, ML | E33
13403-24F00  THROTTLE BODY ASSY, MR | E3,E28
13403-24F10  THROTTLE BODY ASSY, MR | E33
13404-24F00  THROTTLE BODY ASSY, RH | E3,E28
13404-24F10  THROTTLE BODY ASSY, RH | E33
15710-24F00  INJECTOR ASSY
15721-24F00  O RING
15722-24F00  RING, CUSHION
13672-24F00  RING, SEAL
13605-24F00  SCREW
09160-05043 !  WASHER
13471-35F00 !  JOINT, NO.1
13471-35F10 !  JOINT, NO.2,3
13471-35F20 !  JOINT, NO.4
13474-24F00  JOINT
15721-24F00  O RING
13611-24F00  BOLT
13607-24F00  NUT
13602-24F00  SCREW, STOP
13543-24F00  SPRING
13543-24F10  SPRING
13543-24F20  SPRING
13602-24F10  SCREW, STOP
13543-24F30  SPRING
13270-24F00  SCREW, STOP
13273-24F00  WASHER
13271-24F00  SPRING
13580-24F00  SENSOR ASSY, THROTTLE
13582-24F00  COLLAR
13575-24F00  O RING
13613-24F00  SCREW
13572-03F00 !  WASHER
13432-24F10  CLAMP | E3,E28
13619-24F00  CLAMP | E33
13508-24F00  CAP, RUBBER
13692-24F10  CLIP
13697-24F00  HOSE, RUBBER (L:35)
13697-24F20  HOSE, RUBBER (L:100)
13697-24F30  HOSE, RUBBER (L:200)
13697-24F10  HOSE, RUBBER (L:120)
13697-24F40  HOSE, RUBBER (L:110+20)
13471-24F30  JOINT
13432-24F00  CLAMP
13565-24F00  PLATE, STAY
13601-24F00  SCREW
13698-24F00  HOSE, RUBBER (L:80+25) | E33
13698-24F10  HOSE, RUBBER (L:35) | E33
13698-24F20  HOSE, RUBBER (L:30+30) | E33
13698-24F30  HOSE, RUBBER (L:440+30) | E33
13693-24F00  CLIP | E33
13685-36E50  JOINT | E33
13279-24F00  PLATE, IDLE ADJUST
01550-06167  BOLT, IDLE ADJUST PLATE
24120-24F00  SHAFT, COUNTER (NT:13)
24221-24F00  GEAR, 2ND DRIVE (NT:16)
24231-24F00  GEAR, 3RD & 4TH DRIVE | MODEL X,NT:19/21
24231-24F10  GEAR, 3RD & 4TH DRIVE | MODEL Y/K1/K2/K3 NT:19/21
24251-24F00  GEAR, 5TH DRIVE (NT:22)
24252-24F10 !  BUSH, 5TH DRIVE | %JS1GW71A12105462
24252-24F10  BUSH, 5TH DRIVE | JS1GW71A12105463%
24261-24F00  GEAR, 6TH DRIVE (NT:23)
09167-27003  WASHER, 6TH DRIVE
09181-27014  WASHER, 5TH DRIVE
24262-24F10 !  BUSH, 4TH DRIVE | %JS1GW71A12105462
24262-24F10  BUSH, 4TH DRIVE | JS1GW71A12105463%
09263-20085  BEARING, CENTER SHAFT LH
09267-25012  BEARING, CENTER SHAFT RH
09285-20006  SEAL, OIL | 20X31.2X2.7
09380-27004  CIRCLIP, 2ND DRIVE
09380-27006  CIRCLIP, 5TH & 6TH DRIVE
09390-62012  C RING, CNTR SHAFT BRG RH
04221-07209  PIN, CNTR SHAFT BRG LH
24131-24F00  SHAFT, DRIVE | %JS1GW71AY2107287
24131-24F10  SHAFT, DRIVE | JS1GW71AY2107288%
24311-24F00  GEAR, 1ST DRIVEN (NT:34)
24312-24F10 !  BUSH, 1ST DRIVEN | MODEL X/Y
24312-24F10  BUSH, 1ST DRIVEN | MODEL K1/K2/K3
24321-24F00  GEAR, 2ND DRIVEN (NT:31)
24322-24F10 !  BUSH, 2ND DRIVEN | MODEL X/Y
24322-24F10  BUSH, 2ND DRIVEN | MODEL K1/K2/K3
24331-24F00  GEAR, 3RD DRIVEN (NT:29)
24332-24F10 !  BUSH, 3RD & 4TH DRIVEN | MODEL X/Y
24332-24F10  BUSH, 3RD & 4TH DRIVEN | MODEL K1/K2/K3
24341-24F00  GEAR, 4TH DRIVEN (NT:27)
24351-24F10 !  GEAR, 5TH DRIVEN (NT:25) | MODEL X/Y
24351-24F10  GEAR, 5TH DRIVEN (NT:25) | MODEL K1/K2/K3
24361-24F00  GEAR, 6TH DRIVEN (NT:24) | MODEL X/Y
24361-24F10  GEAR, 6TH DRIVEN (NT:24) | MODEL K1/K2/K3
09167-30008  WASHER, 3RD DRIVEN GEAR LH
09167-30008  WASHER, 4TH DRIVEN GEAR RH
09167-30008  WASHER, 3RD & 4TH DRIVEN
09181-20251  WASHER, 1ST DRIVEN RH | 20X34X1
09181-24005  WASHER, 1ST DRIVEN LH
09263-20040  BEARING, DRIVE SHAFT RH | 20X34X20
09267-30011  BEARING, DRIVE SHAFT LH | 30X62X23.8
09283-42017  SEAL, DRIVE SHAFT | 38X52X8
09380-30009  CIRCLIP, 2ND DRIVEN
09380-30009  CIRCLIP, 3RD DRIVEN
09380-30009  CIRCLIP, 4TH DRIVEN
04221-07209  PIN, DRIVE SHAFT BRG RH
08211-30405  WASHER, 2ND DRIVEN GEAR RH | 30X40X2,5
27510-21A31  SPROCKET, ENGINE (NT:17)
27531-24F00  SPACER, SPROCKET
27600-24F50-112 !  CHAIN ASSY,DRIV | Includes Item(s) 43
27620-24F00  JOINT SET, DRIVE
09159-20004  NUT
09181-25268  WASHER (25X40X1.5)
35601-24F00  LAMP ASSY, FRONT TURNSIGNAL RH
35602-24F00  LAMP ASSY, FRONT TURNSIGNAL LH | Includes Item(s) 2 - 6
35610-24F00  LAMP UNIT, RH
35630-24F00  LAMP UNIT, LH
35618-24F00  SOCKET & CORD RH
35638-24F00  SOCKET & CORD LH
09471-12045  BULB(12V,21W)
03541-0516A !  SCREW
35603-33E30  LAMP ASSY, REAR TURNSIGNAL RH
35604-33E30  LAMP ASSY, REAR TURNSIGNAL LH | Includes Item(s) 9 - 11
35610-33E00  LAMP UNIT
03242-0412B !  SCREW
09471-12045  BULB (12V,21W)
35695-17C00  SPACER, REAR TURNSIGNAL LAMP
09160-10501  WASHER (10.5X30X2.3)
08310-0010A !  NUT, REAR TURNSIGNAL LAMP
38610-03F00  RELAY ASSY, TURNSIGNAL LAMP
94520-24F00  BRACKET, PANEL RH
94530-24F00  BRACKET, PANEL LH
01550-0620A !  BOLT, SHIFT LEVER
09320-08018  CUSHION
03541-0508A !  SCREW
94484-24F00  NUT
09409-07332  CLIP, SIDE PANEL
09139-06126 !  SCREW
09320-09016  CUSHION
09139-05054  SCREW, LOWER
09409-06314-5PK  CLIP, INNER PANEL (BLACK)
03541-0512A !  SCREW
94540-24F01 !  BRACKET, REAR COWL | MODEL X/Y
94540-24F01  BRACKET, REAR COWL | MODEL K1/K2/K3
01550-1020A !  BOLT, PROP SHAFT REAR
09320-09016  CUSHION
09139-06126 !  SCREW
94550-24F00  BRACKET, UNDER COWL LH
09321-05019  CUSHION, RH
94561-24F01 !  PLATE,UNDER COW | MODEL Y/K1/K2/K3
09139-05054  SCREW | MODEL Y/K1/K2/K3
94407-24F21-CN5 !  COWL ASSY,UNDER
94407-24F21-FH5 !  COWL ASSY,UNDER
94407-24F20-FH6  COWL ASSY, UNDER RH
94408-24F21-CN5 !  COWL ASSY,UNDER
94408-24F21-FH5 !  COWL ASSY,UNDER
94408-24F20-FH6  COWL ASSY, UNDER LH | Includes Item(s) 3 - 8
68181-24F20-FJ9  EMBLEM, RH | FOR CN5
68181-24F20-FK1  EMBLEM, RH | FOR FH5
68181-24F20-FK2  EMBLEM, RH | FOR FH6
68191-24F20-FJ9  EMBLEM, LH | FOR CN5
68191-24F20-FK1  EMBLEM, LH | FOR FH5
68191-24F20-FK2  EMBLEM, LH | FOR FH6
94474-24F01  CUSHION
94476-41G00 !  CUSHION, UNDER COWL RH
94475-24F01  CUSHION, RH
94485-24F00  CUSHION, LH
94621-24F00  PANEL, SIDE RH
94631-24F00  PANEL, SIDE LH
94622-24F00  MOLDING, SIDE PANEL
94461-24F00  COWL, INNER RH
94462-24F00  COWL, INNER LH
94498-24F01  COWL, CENTER
94660-24F00-1LF  COWL, REAR (BLUE) | FOR CN5
94660-24F00-33J  COWL, REAR (BLACK) | FOR FH5
94660-24F00-YC6  COWL, REAR (RED) | FOR FH6
94482-24F00 !  CUSHION, UNDER COWL LH
94482-24F00  CUSHION, UNDER COWL LH
94407-24F20-YZX  COWL ASSY, UNDER RH | GSX1300RK2
94407-24F21-FH9 !  COWL ASSY,UNDER | GSX1300RK2
94407-24F31-HE6 !  COWL ASSY,UNDER | GSX1300RK2
94407-24F41-019 !  COWLING ASSY,UN | GSX1300RZK2
94408-24F20-YZX  COWL ASSY, UNDER LH | GSX1300RK2
94408-24F21-FH9 !  COWL ASSY,UNDER | GSX1300RK2
94408-24F31-HE6 !  COWL ASSY,UNDER | GSX1300RK2
94408-24F41-019 !  COWL ASSY,UNDER | GSX1300RZK2; Includes Item(s) 3 - 8
68181-24F20-YY6  EMBLEM, RH | GSX1300RK2 FOR YZX
68181-24F20-YY7  EMBLEM, RH | GSX1300RK2 FOR FH9
68181-24F30-YY8  EMBLEM, RH | GSX1300RK2 FOR HE6
68181-24F10-JB6  EMBLEM, RH | GSX1300RZK2 FOR 019
68191-24F20-YY6  EMBLEM, LH | GSX1300RK2 FOR YZX
68191-24F20-YY7  EMBLEM, LH | GSX1300RK2 FOR FH9
68191-24F30-YY8  EMBLEM, LH | GSX1300RK2 FOR HE6
68191-24F10-JB6  EMBLEM, LH | GSX1300RZK2 FOR 019
94474-24F01  CUSHION
94476-41G00 !  CUSHION, UNDER COWL RH
94475-24F01  CUSHION, RH
94485-24F00  CUSHION, LH
94621-24F00  PANEL, SIDE RH
94631-24F00  PANEL, SIDE LH
94622-24F00  MOLDING, SIDE PANEL
94461-24F00  COWL, INNER RH
94462-24F00  COWL, INNER LH
94498-24F01  COWL, CENTER
94660-24F00-YD8  COWL, REAR (SILVER) | GSX1300RK2 FOR YZX,HE6
94660-24F00-YC2  COWL, REAR (BLUE) | GSX1300RK2 FOR FH9
94660-24F10-019  COWL, REAR (BLACK) | GSX1300RZK2 FOR 019
94407-24F60-CN5  COWL ASSY, UNDER RH | GSX1300RK3
94407-24F61-KT7 !  COWL ASSY,UNDER | GSX1300RK3
94407-24F61-LA1 !  COWL ASSY,UNDER | GSX1300RK3
94407-24F41-019 !  COWLING ASSY,UN | GSX1300RZK3 E28
94407-24F11-YAV !  COWL ASSY,UNDER | GSX1300RZK3 E3,E33
94408-24F60-CN5  COWL ASSY, UNDER LH | GSX1300RK3
94408-24F61-KT7 !  COWL ASSY,UNDER | GSX1300RK3
94408-24F61-LA1 !  COWL ASSY,UNDER | GSX1300RK3
94408-24F41-019 !  COWL ASSY,UNDER | GSX1300RZK3 E28
94408-24F11-YAV !  COWL ASSY,UNDER | GSX1300RZK3 E3,E33; Includes Item(s) 3 - 8
68181-24F40-LL1  EMBLEM, RH | GSX1300RK3 FOR CN5
68181-24F40-LL2  EMBLEM, RH | GSX1300RK3 FOR KT7
68181-24F40-LL3  EMBLEM, RH | GSX1300RK3 FOR LA1
68181-24F10-JB6  EMBLEM, RH | GSX1300RZK3 E28 FOR 019
68181-24F10-NH5  EMBLEM, RH | GSX1300RZK3 E3,E33 FOR YAV
68191-24F40-LL1  EMBLEM, LH | GSX1300RK3 FOR CN5
68191-24F40-LL2  EMBLEM, LH | GSX1300RK3 FOR KT7
68191-24F40-LL3  EMBLEM, LH | GSX1300RK3 FOR LA1
68191-24F10-JB6  EMBLEM, LH | GSX1300RZK3 E28 FOR 019
68191-24F10-NH5  EMBLEM, LH | GSX1300RZK3 E3,E33 FOR YAV
94474-24F01  CUSHION
94476-41G00 !  CUSHION, UNDER COWL RH
94475-24F01  CUSHION, RH
94485-24F00  CUSHION, LH
94621-24F00  PANEL, SIDE RH
94631-24F00  PANEL, SIDE LH
94622-24F00  MOLDING, SIDE PANEL
94461-24F00  COWL, INNER RH
94462-24F00  COWL, INNER LH
94498-24F01  COWL, CENTER
94660-24F00-YD8  COWL, REAR (SILVER) | GSX1300RK3 FOR CN5,LA1
94660-24F00-YU8  COWL, REAR (GRAY) | GSX1300RK3 FOR KT7
94660-24F10-019  COWL, REAR (BLACK) | GSX1300RZK3 E28 FOR 019
94660-24F00-YAV  COWL, REAR (ORANGE) | GSX1300RZK3 E3,E33 FOR YAV
94407-24F03-M9S !  COWL ASSY,UNDER | USE WITH 09250-08013 *
94407-24F03-M9T !  COWL ASSY,UNDER | USE WITH 09250-08013
94408-24F03-M9S !  COWL ASSY,UNDER | USE WITH 09250-08013 *
94408-24F03-M9T !  COWL ASSY,UNDER | USE WITH 09250-08013 *; Includes Item(s) 3 - 7
68181-24F00-N1F  EMBLEM, RH | FOR M9S
68181-24F00-N1G  EMBLEM, RH | FOR M9T
68191-24F00-N3B  EMBLEM, LH | FOR M9S
68191-24F00-N1G  EMBLEM, LH | FOR M9T
94474-24F01 !  CUSHION
94475-24F01 !  CUSHION, RH
94485-24F00  CUSHION, LH
94621-24F00  PANEL, SIDE RH
94631-24F00  PANEL, SIDE LH
94622-24F00  MOLDING, SIDE PANEL
94461-24F00  COWL, INNER RH
94462-24F00  COWL, INNER LH
94498-24F01 !  COWL, CENTER
94660-24F00-Y4H  COWL, REAR (SILVER) | FOR M9S
94660-24F00-24K  COWL, REAR (CHARCOAL) | FOR M9T
94482-24F00 !  CUSHION, UNDER COWL LH
94482-24F00  CUSHION, UNDER COWL LH
94407-24F03-CN4 !  NO DESCRIPTION AVAILABLE
94407-24F03-CN5 !  COWL ASSY,UNDER
94407-24F03-M9T !  COWL ASSY,UNDER | E28
94408-24F03-CN4 !  COWL ASSY,UNDER
94408-24F03-CN5 !  COWL ASSY,UNDER
94408-24F03-M9T !  COWL ASSY,UNDER | E28; Includes Item(s) 3 - 7
68181-24F00-CN9  EMBLEM, RH | FOR CN4
68181-24F00-CP1  EMBLEM, RH | FOR CN5
68181-24F00-N1G  EMBLEM, RH | E28 FOR M9T
68191-24F00-CP2  EMBLEM, LH | FOR CN4
68191-24F00-CP3  EMBLEM, LH | FOR CN5
68191-24F00-N1G  EMBLEM, LH | E28 FOR M9T
94474-24F01  CUSHION
94475-24F01  CUSHION, RH
94485-24F00  CUSHION, LH
94621-24F00  PANEL, SIDE RH
94631-24F00  PANEL, SIDE LH
94622-24F00  MOLDING, SIDE PANEL
94461-24F00  COWL, INNER RH
94462-24F00  COWL, INNER LH
94498-24F01 !  COWL, CENTER
94660-24F00-17U  COWL, REAR (GRAY) | FOR CN4
94660-24F00-YD8  COWL, REAR (SILVER) | FOR CN5
94660-24F00-24K  COWL, REAR (CHARCOAL) | E28 FOR M9T
94482-24F00 !  CUSHION, UNDER COWL LH
94482-24F00  CUSHION, UNDER COWL LH
17400-24F10 !  PUMP ASSY, WATER | Includes Item(s) 2 - 12
17491-17E01  IMPELLER
09168-06025  GASKET
17470-02F00 !  SEAL, MECHANICAL | MODEL X/Y
17470-02F00  SEAL, MECHANICAL | MODEL K1/K2/K3
09283-10004  OIL SEAL (10X21X5)
17511-24F00  SHAFT
09262-10014  BEARING (10X26X8)
09164-06006  LOCK WASHER
17418-33400  O RING
17435-33400  O RING
02112-0616A !  SCREW
09100-06099  BOLT (6X13)
01547-0635B !  BOLT
36610-24F60  HARNESS, WIRING NO.1 | Includes Item(s) 2 - 5
09481-10501  FUSE (10A)
09481-15501  FUSE (15A)
36618-33E00  BOOT, METER COUPLER
36611-24F00  PROTECTOR, WIRING HARNESS
36619-24F00  GUIDE, WIRING HARNESS
36620-24F10  HARNESS, WIRING NO.2
36856-24F10  WIRE, INJECTION LEAD
09404-06432  CLAMP (L:65) | T:1.0
09404-06432 !  CLAMP (L:65) | T:0.7
09404-06434 !  CLAMP
09407-14403  CLAMP (L:125)
09407-18402  CLAMP (L:165)
09407-11402  CLAMP (L:60)
09407-17402 !  CLAMP, WATER HOSE
01550-0610A !  BOLT
36744-24F00  BRACKET, FUSE BOX
07120-0510B !  SCREW, FUSE BOX
37000-24810  LOCK SET
37000-24830  LOCK SET | E33; Includes Item(s) 16
37100-24F00  LOCK ASSY, STEERING
09139-08016  SCREW (8X20)
37740-24A00  SWITCH ASSY, STOP LAMP
09443-06012  SPRING
37840-24F00  SWITCH ASSY, SIDE STAND
09103-08357  BOLT (8X35)
08316-1008B !  NUT
38500-24F00  HORN ASSY
07120-0612B !  PLUG
38740-26E00  RELAY ASSY, FUEL PUMP
38741-24F00  BRACKET, FUEL PUMP RLY
01550-0612A !  BOLT, REAR COMB BRACKET
38740-26E00  RELAY ASSY, FAN MOTOR
36851-17E10  WIRE, OIL PRESSURE
37146-33E00  KEY, BLANK | OPT
36610-24F10  HARNESS, WIRING NO.1 | MODEL X
36610-24F20  HARNESS, WIRING NO.1 | MODEL Y
36610-24F30  HARNESS, WIRING NO.1 | MODEL K1/K2; Includes Item(s) 2 - 3B
09481-10501  FUSE (10A)
09481-15501  FUSE (15A)
36618-33E00  BOOT, METER COUPLER
36611-24F00  PROTECTOR, WIRING HARNESS
36619-24F00  GUIDE, WIRING HARNESS
36620-24F10  HARNESS, WIRING NO.2
36854-24F00  WIRE, SENSOR LEAD | MODEL X/Y
36855-24F00  WIRE, 02 SENSOR | MODEL K2
36856-24F00  WIRE, INJECTION LEAD | MODEL X/Y
36856-24F10  WIRE, INJECTION LEAD | MODEL K1/K2
09404-06432  CLAMP (L:80)
09404-06434  CLAMP (L:95)
09407-14403  CLAMP (L:125)
09407-18402  CLAMP (L:165)
09407-11402  CLAMP (L:90)
09407-17402 !  CLAMP, WATER HOSE | MODEL K1
01550-0610A !  BOLT
36744-24F00  BRACKET, FUSE BOX
07120-0510B !  SCREW, FUSE BOX
37000-24810  LOCK SET
37000-24830  LOCK SET | E33; Includes Item(s) 15
37100-24F00  LOCK ASSY, STEERING
09139-08016  SCREW (8X20)
37740-24A00  SWITCH ASSY, STOP LAMP
09443-06012  SPRING
37840-24F00  SWITCH ASSY, SIDE STAND
09103-08357 !  BOLT, REAR FINAL GR | MODEL X
09103-08357  BOLT (8X35) | MODEL Y/K1/K2
08316-1008B !  NUT
38500-24F00  HORN ASSY
07120-0612B !  PLUG
38740-26E00  RELAY ASSY, FUEL PUMP
38741-24F00  BRACKET, FUEL PUMP RLY
01550-0612A !  BOLT, REAR COMB BRACKET
38740-26E00  RELAY ASSY, FAN MOTOR
36851-17E10  WIRE, OIL PRESSURE | MODEL X/Y/K1 ?36851-24F00
37146-33E00  KEY, BLANK | OPT
